Power Driver Board Continued ...
J126-1
Black-Brown, sol
17
drive, to left
EMI
Board.
J1-1
J126-2
Black-Red, sol.
18
drive, to right
EMI
Board
J1-1
J126-3
Black-Orange, sol.
19
drive, to playfield flashlamps
J126-4
Black-Yellow, sol.
20
drive, to playfield flashlamps
J126-5
Blue-Green,
501.21
drive, to playfield flashlamps
J126-6
Blue-Black, sol.
22
drive, to playfield ftashlamps
J126-7
Blue-Violet, sol.
23
drive, to playfield flashlamps
J126-8
Blue-Gray, sol.
24
drive, to playfield flashlamps
J126-9 N/C
J126-10 N/C
J126-11 N/C
J126-12 N/C
J126-13 N/C
J127-1
Brown-Black, sol. 9 drive, to playfield coil
J127-2
N/c
J127-3
Brown-Red, sol. 10 drive, to playfield ooil
J127-4
Brown-Orange, sol.
11
drive, to playfield coil
J127-5
Brown-Yellow, sol.
12
drive, to playfield coil
J127-6
Brown-Green, sol.
13
drive, to playfield ooil
J127-7
Brown-Blue, sol. 14 drive, to playfield coil
J127-8
Brown- Violet, sol. 15 drive, to playfield ooil
J127-9
Brown-Gray, sol.
16
drive, to playfield coil
J128-1
N/C
J128-2
N/C
J128-3
N/C
J128-4
N/C
J128-5
N/C
J129-1
N/C
J129-2
N/c
J129-3
N/C
J129-4
N/C
J129-5
N/C
J130-1
VIOlet-Brown, sol. 1 drive, to playfield coil
J130-2
VIOlet-Red, sol. 2 drive, to playfield coil
J130-3
N/C
J130-4
Violet-Orange, sol.
3
drive, to playfield coil
J130-5
Violet-Yellow,
501.4
drive, to playfield coil
J130-6
Violet-Green,
sol. 5 drive, to playfield coil
J130-7
Violet-Blue, sol. 6 drive, to playfield coil
J130-8
VIOlet-Black,
501.7
drive, to playfield coil
J130-9
Violet-Gray, sol. 8 drive, to playfield coil
J131-1
N/C
J131-2
N/C
J131-3
N/C
J131-4
N/C
J131-5
N/C
J132-1
N/C
J132-2
N/C
J132-3
N/C
J132-4
N/C
J132~5
N/C
J133-1 N/C
J133-2 N/C
J133-3
N/C
J133-4
N/C
J133-5
N/C
J133-6
N/C
J133-7
Red-Blue, lamp row
6,
not used
J133-8
Red-Violet, lamp row
7,
to cabinet
J133-9
Red-Gray, lamp row
8,
to cabinet
J134-1
N/C
J134-2
N/C
J134-3
N/C
J134-4
N/C
Jl34-5
N/C
J134-6
N/C
J134-7
N/C
Jl34-8
N/C
J134-9
N/C
J135-1
Red-Brown, lamp row
1,
to playfield lamps
J135-2
Red-Black, lamp row
2,
to playfield lamps
J135-3
N/C
J135-4
Red-Orange, lamp row
3,
to playfield lamps
Jl35-5
Red-Yellow, lamp row
4,
to playfield lamps
J135-6
Red-Green, lamp row
5,
to playfield lamps
J135-7
Red-Blue, lamp row
6,
to play field lamps
Jl35-8
Red-Violet, lamp row
7,
to playfield lamps
J135-9
Red-Gray, lamp row
8,
to playfield lamps
J136-1
N/C
Jl36-2
N/C
J136-3
Yellow-Gray, lamp column
8,
to cabinet
J137.1
N/C
J137-2
N/C
J137-3
N/C
J137-4
N/C
J137-5
N/C
J137-6
N/C
J137-7
N/C
J137-8
N/C
J137-9
N/C
J138-1
Yellow-Brown, lamp oolumn
1,
to playfield lamps
J138-2
Yellow-Red, lamp oolumn
2,
to playfield lamps
J138-3
Yellow-Orange, lamp column
3,
to playfield lamps
J138-4
Yellow-Black, lamp column
4,
to playtield lamps
J138-5
Yellow-Green, lamp column
5,
to playfield lamps
Jl38-6
Yellow-Blue, lamp column
6,
to play field lamps
J138-7
Yellow-Violet,
lamp column
7,
to playfield lamps
J138-8
N/C
J138-9
Yellow-Gray, lamp column
8,
to playfield lamps
