A-17811
Kicker Arm
(Slingshot)
Assembly
80
89
:
I
I
i
l .
"
I
"
I
"
I
"
I
'0
Associated Parts for Right & Left Kickers:
Item Part Number
Description
Item Part Number
Description
1 02-2364
Coil Plunger
8 B-9362-L-2
Coil & Bracket Assembly, L.
2 A-1781O
Mounting Bracket Assembly
B-9362-R-3
Coil & Bracket Assembly, R.
3 A-12664
Kicker Crank Assembly
a) A-17808
Bracket & Stop Assembly
4 12-6227
Hairpin Clip
b) 01-8-508-S
Coil Retaining Bracket
5 4700-00030-00 FW, 17/64 x 1/2 x 15ga.
c) 4006-01017 -06 Mach. Screw, 6-32 x 3/8"
6 03-8085
Armature Link
d) 4406-01119-00 Nut, 6-32 ESN
7 20-8716-5
Roll Pin, 1/8 x 7/16"
e) AE-26-1200
Coil Assembly
f)
03-7066
Coil Tubing
g)
H-19523-1
Mini Solenoid Cable
9 10-128
Spring
2-18
