A-20909
48 Lamp & Driver PCB Assembly
o
Part Number
Designator
Description
5040-09343-00
Cl
Cap" 10m, 20V (±20%) Ax.
5043-08996-00
C2-C7, C9
Cap., 0.1 m, 50v (±20%) Ax.
5048-10994-00
C8
Cap., ,33mFD, 50V (±20%) Ax.
5070-09054-00
01
Diode 1N4004, 1.0A.
5070-08919-00
02-017, 020-029,
030-
Diode lN4148 150mA.
035,038·053
5070-09045-00
018,019,036,037,
Diode MR501 3.0A.
054, D55
24-8767
L1-L48
Lamp Skirt PCB Twist
5791-13830-07
Jl
Connector, 7 -pin Header
5791-10862-13
J8
Connector,
13-pin Header
5671-14516-00
LEOI
LED Display Red T-l 10
24-8768
L1-L48
Bulb #555 6.3v, 0.25A.
5162-13514-00
Ql-Q48
Trans. 2N6426 NPN DAR
5010-09358-00
Rl, R2, R4, R5, R7, R8,
Resistor, lKn, 1/4w, 5%
RIO, Rll
5010-09416-00
R120
Resistor, 470n, !14m, 5%
5370-12272-00
Ul
IC LM339 Quad Comp
5310-14760-00
U2-U7
IC 4094 Parallel Out Shift Reg
()
G
o
G
0
i
0
,
~
8
0
W.
-IIIID-
-w
••
~
@~
III
Part Number
Designator
Description
50 10-09034-00
R3, R6, R9, R12-R14, R16, R18, R20,
Resistor, 10ka, 1/4w, 5%
R22,R24,R26,R2B,R30,R32,R34,
R36, R38,R40,R42,R44,
R46,R47,
R49, R51,R53, R55, R57, R59, R61,
R63, RS5, RS7, R69, R71, R73, R75,
Rn, R79, RBO, R82, R84, R86,R88,
ROO, R92, R94, R96, R9B,
Rl00, Rl02, Rl04, Rl0S, Rl08, Rll0,
RI12-RI17,
R121-R123
R15, R17, R19, R21, R23, R25,
Resistor, 2Kn, 1/4w, 5%
R27, R29, R31, R33, R35, R37,
R39, R41, R43, R45, R48,R50, R52,
R54, R5S, R5B, R60, R62, R64, R66,
RS8, R70, R72, R74, R76, R78, R81,
R83, R85, RB7, RB9, R91, R93, R95,
R97, R99, Rl01, R103, R105, R107.
R109, R111
5070-09999-00
2-14
