WPC '95 CPU PCB Assembly
Part Number
Designator
Description
A-15814
Bl
Battery Holder
5048-11033-00
ci,
C42
Cap., .022~. 50v, 10% Ax.
5048-11030-00
C3-C26, C34-C41
Cap., 470p, 50v Axial
5043-09030-00
C27
Cap., .047m, 50v (±20%) Ax.
5048-13375-00
C28
Cap., lOOp, 50v, 10% Axial
5048-11028-00
C29, C30, C43, C44
Cap., 22p, 50v Axial
5040-14569-00
C31
Cap., 1OO~, 25v, Axial
5048-11031-00
C32
Cap., .001~, 50v, Axial
5043-08996-00
C45 -C70
Cap., 0.1~, 50v (±20%) Ax.
5040-13098-00
C73
Cap., 4.7~F, 35v (±20%)
5645-09025-00
DIPSWl
Switch Dip 8-Position
5070-09266-00
01,025,028
Diode 1N5817 1.0A.
5070-08919-00
02 - 024, 026, 027
Diode lN4148150mA.
5700-10176-00
Gl0
Socket Dip 28.6
5700-12088-00
Gll
Socket Dip 32.6p"
5700-08985-00
U4
IC Socket 40-pin
5700-12424-00
U9
Socket 84-pin
5700-10389-00
U20
IC Socket 18-pin 3"
5791-10850-00
J201
Connector, 26-pin Header
5791-12516-00
J202,J211
Connector, 34-pin Hdr. 2x17
5791-13830-12
J205
Connector, 12-pin Header Str.
5791-13830-09
J206,J207,J209
Connector, 9-pin Header
5791-13830-14
J208
Connector, 14-pin Header
5791-10862-07
J210
Connector, 7-pin Header
5791-13830-13
J212
Connector, 13-pin Header
5671-14516-00
LED201 - LED203
LED Dspl. Red
T-1-3/4
5160-10269-00
Q1
Transistor, 2N3904 NPN
5019-09669-00
RPl
SIP 4.7K, 9R, 10 (5%)
5010-09358-00
Rl-R4, R9-Rl1,
Resistor, tkn,
1/4W, 5%
R23-R26, R43-R84,
R93, R9S-R97, R99-R114,
Rl17
5010-08774-00
R129
Resistor, 22Kn,
1/4w, 5%
5010-09416-00
R5-R8, R12, R13,
Resistor, 4700,
1/4w, 5%
R87-R89
5010-09034-00
R14-R22, R27-R42,
Resistor, 10Kn,
1/4w, 5%
R86, R90, R94, R98
5010-12104-00
R91
Resistor, 22M,
1/4w, 5%
5010-10989-00
R92
Resistor, 470Kn,
1/4w, 5%
5010-09187-00
Rl18 - R123, R128
Resistor, 1500, 1I4w, 5%
5010-09040-00
R127
Resistor, 33n, 1I4w, 5%
501 0-09534-00
W3, W4, W7, R124, R125 Resistor, on
5010-10258-00
R126
Resistor, 1M, 5%
1/4w
5281-09867-00
Ul, U2, U7
I.C. 74HCT244
5281-09851-00
U5
I.C. 74LS14 SMTITRG
5281-09308-00
U3
IC 74LS245 Trnc
5340-13062-00
U8
IC RAM 32k x 8 Static
5370-12687-00
Ul0
I.C. MC 34064 Reset Chp.
5281-10182-00
U11-U13, U15
I.C. 74LS240
Vdrvr
5311-14068-00
U14,U24
I.C. 74HC574 Octal d-latch
5370-12272-00
U16-U19, U25, U26
I.C. LM339 Quad Compo
5284-12651-00
U21
I.C. 4584 Hex Schmitt
5311-14554-00
U23
I.C. 74HC237 3 to 8 non inv
5281-09743-00
U27
I.C. 74LS08 Quad.
5520-12084-00
Xl
Crystal 32.768KHz
5520-14761-00
X2
Xtal-8M Anti Res Parallel Cut
A-5400-90003-1
Gl0
PIC16C57 Assembly
5880-09022-00
Bl
Battery 1.5v AA Alkaline
5400-10320-00
U4
I.C. MPU68B09E
5410-12426-00
U9
I.C. WPC-89 ASIC
5162-12422-00
U20
Trans uln 2803 Oc-Drl
A-5343-90003-1 A Gll
