90003-CAB
Cabinet Assembly
Item Part Number
Description
Part Number
Description
1 A-16883-4
Button Assy. w/Spring, Red (2)
01-14016
Cashbox Lock Plate
2 A-17195-1
Slam Tilt Switch w/Cable
01-6389-2
Cashbox Nest Bracket
3 A-17316
Flipper Opto Assembly (2)
09-85000-1
Coin Door 2-Slot
4 A-17540-1
Univ. Power Interface Assy.
A-19514
Leg Assembly, Chrome (4)
5 A-18249-1
Interlock Switch & Bracket Assy.
01-10714
Line Cord Cover
6 A-19562.1
Stay Arm Assembly
04-10362
Front Molding Assembly
7 A-20949
Coin Door Interface PCB Assy.
08-8103
Playfield Glass
8 B-12445
Ball Shooter Assembly
20-6502-A
Plumb Bob
9 01-8169
Vent Hole Screen
10 01-12352
Clip Bracket
A-20201
Cable & Jumper Plug Assembly
11 01-3535
Rod Mounting Plate
H-17217.1
Plumb Bob/Mem. Protect Cable
12 01-14085
Hasp Hinge Bracket
H-17837-2
Voltage Program Jumper Cable
13 01-14086
Hasp Staple Bracket
H-20841
Cabinet Sw/Lamp Cable
14 03-7135-9
Side Molding 35-7/8" (2)
H-20924.1
Cabinet Cable
15 03-8091.1-3
Rear Molding
H-20925
Slam Tilt Switch Cable
16 03-8603-2
Vent Screen, 2-1/2" Square
H-20992
Secondary Cable
17 04-10346
Tilt Mechanism Assembly
18 11-1323.2
Cabinet, Wood
19 20-9347
Toggle Latch
20 20-9663-16
Push Button w/Switch, Yellow
21 23-6303
White Rubber Ring, 1-1/4"
22 5555-12929-00 Speaker, 40, 6", 25w
23 5610-14515-00 WPC Transformer, Wide Mount
2-3
