U.9 06 Install 5 Ball
U.9 07 Install 3 Ball
Adjustments U.9 06 and U.9 07 can be used to change a game to 3 or 5
ball play, including the changing of certain features to the recommended 3- and 5-ball level. The
Preset Game Adjustments Table for U.S./Canadian Games lists the adjustments and settings
that comprise the individual groups.
rese arne
IJUS
men
S
a e
Adjustment
Adjustment
Install 3-Ball
InstallS Ball
Number
Description
U.9 07
U.9 06
(factory)
p
tG
Ad"
t
t
T bl
U.9 08 Install Add-A-Ball
This option deletes all Free Play awards and replaces them with Extra
Ball awards. Individual adjustments are affected, as follows:
Adjustment
Name
New Setting
A.1 13 Replay Boost
Off
A.1 14 Replay Award
Extra Ball
A.1 15 Special Award
Extra Ball
A.1 17 Extra Ball Ticket
No
A.1 19 Match Feature
Off
A.4 04 Champion Credits
00
A.4 05 High Score 1 Credits 00
A.4 06 High Score 2 Credits 00
A.408 High Score 3 Credits 00
A.4 07 High Score 4 Credits 00
A.4 20 Alien Champion Credits 00
U.9 09 Install Ticket
This option deletes Credit awards and replaces them with Ticket awards.
Individual adjustments are affected, as follows:
Adjustment
Name
A.1 14 Replay Award
A.1 15 Special Award
A.1 16 Match Award
A.1 17 Extra Ball Ticket
A.1 31 Ticket Expansion Board
A.4 02 H.S.T.D. Award
New Setting
Ticket
Ticket
Ticket
Yes
Yes
Ticket
1-23
