10 OPTO p.e.B.
A-18159
J1-1 Gray-Violet to A-16908 (LED) Sw #37
J1-2 Gray-Blue to A-16908 (LED) Sw #36
J1-3 Gray-Green to A-18617-1 (LED) J1-3 Sw#35
J1-4 Gray-Black to A-18617-1 (LED) J1-4 Sw#34
J1-5 Gray-Orange to A-18617-1 (LED) J1-5 Sw #33
J1-6 Gray-Red to A-18617-1 (LED) J1-6 Sw #32
J1-7 Gray-Brown to A-18617-1 (LED) J1-7 Sw #31
J1-8 Key
J1-9 Black Ground to A-18617-1 J1-9
J2-1 Orange-Violet to A-16909 (Trans.) Sw #37
J2-2 Orange-Blue to A-16909 (Trans.) Sw #36
J2-3 Orange-Green to A-18618-1 (Photo) J1-7 Sw #35
J2-4 Orange-Yellow to A-18618-1 (Photo) J1-6 Sw #34
J2-5 Orange-Black to A-18618-1 (Photo) J1-5 Sw #33
J2-6 Key
J2-7 Orange-Red to A-18618-1 (Photo) J1-4 Sw #32
J2-8 Orange-Brown to A-18618-1 (Photo) J1-3 Sw #31
J2-9 Gray-Yellow +12VOC to A-18618-1 (Photo) JH
J4-1 Gray-Orange to A-16908 (LED) Sw #43
J4-2 Not Used
J4-3 Not Used
J4-4 Key
J4-5 Orange-Black to A-16909 (Trans.) Sw #43
J5-1 Gray-Red to A-16908 (LED) Sw #42
J5-2 Not Used
J5-3 Key
J5-4 Not Used
J5-5 Orange-Red to A-16909 (Trans.) Sw #42
J6-1 Gray-Brown to A-16908 (LED) Sw #41
J6-2 Key
J6-3 Black Ground
J6-4 Gray-Yellow +12VOC
J6-5 Orange-Brown to A-16909 (Trans.) Sw #41
3-18
