Lamp Locations
o
57
87
o
58
o
56
88
Item Bulb
Lamp Assy.
Description
Item Bulb
Lamp Assy.
Description
No.
No.
No.
No.
No.
No.
71 24-6549 A-17835
Bottom Right 3-Bank Top
83 24-8768 B-9414-3
Right Jet (Red)
72 24-6549 A-17807
Bottom Right 3-Bank Middle
84 24-6549 04-10083
Bank Left
73 24-6549 A-17835
Bottom Right 3-Bank Bottom 85 24-6549 04-10083
Bank Right
74 24-6549 A-17835
Bottom Left 3-Bank Top
86 24-6549 A-16041
Vari Break In
75 24-6549 A-17807
Bottom Left 3-Bank Middle
87 24-6549 A-16041
Roof Break In
76 24-6549 A-17835
Bottom Left 3-Bank Bottom 88
20-9663-16 Start Button
77 24-6549 A-17835
Left Return
78 24-6549 A-17835
Left "Extra Time"
24-8768 = #555 Bulb
81 24-8768 B-9414-3
Top Jet (Yellow)
24-6549 = #44 Bulb
82 24-8768 B-9414-3
Left Jet (Clear)
