A-16713
V-Pad Kicker Assembly
Item Part Number
1 A-11396
2 A-16714
3 02-2364
4 12-6227
5 4700-00030-00
6 03-8085
7 20-8716-5
Associated Assemblies:
8 A-21034
a)
A-17808
b)
01-8-508-S
c)
AE-24-900
d)
4006-01017-06
e)
4406-01119-00
f)
03-7066
g)
H-19523
Description
Mounting Bracket Assy.
V-Pad Crank Assembly
Coil Plunger
Hair Pin Clip
FW, 17/64 x ~ x 15ga.
Armature Link
Roll Pin, 1/8 x 7/16"
Coil Bracket Assembly
Bracket
&
Stop Assy.
Coil Retainer Bracket
Coil Assembly
MS, 6-32 x 3/8"
Nut 6-32 ESN
Coil Tubing
Cable
B-12445
Ball Shooter Assembly
Item Part Number
1 03-7357
2 10-148
3 10-149
4 20-8714-37
5 20-9253-7
6 21-6645-1
7 23-6327
8 4700-00051-00
Associated Assemblies:
9 01-3535
10 4010-01006-10
Description
Ball Shooter Sleeve
Spring, Black
Rod Spring
Ext. Retaining Ring, 3/8"
Shooter Rod Assembly
Ball Shooter Housing
Tip
FW, 25/64 x 5/8 x 16ga.
Rod Mounting Plate
MS, 10-32 x 5/8"
2-37
