A-20905
Speaker Display Token Insert Assembly
{"""
"
r
Item Part Number
Description
Item Part Number
Description
1 03-9500
Loading Funnel
34 4008-01168-1 0 Mach. Screw, 8-32 x
5/8"
2 04-10405.1
Token Chute
35 RM-21-06
#18 Vinyl Sleeve
3 04-10406.1-1
Dispenser Bracket, Right
36 03-6047-13
Spacer,
5/8"
Long
4 04-10406.1-2
Dispenser Bracket, Left
37 4406-01128-00
Nut 6-32 KEPS
5 A-21 038
Shuttle & Plunger Assembly
38 4700-00005-00
FW,
9/64
x
7/16
x 21 gao
6 04-10424
Coin Dispenser Coil Assy.
39 04-10397
Speaker Panel Sub-Assy.
7 03-9503.1
Tube Base
40 4106-01115-06Y Sh. Metal Screw, #6 x
3/8"
8 03-9501.1
Token Tube
41 5045-12914-00
Capacitor, 10IJ, 50v (±20%)
9 01-14331.1
Reinforcement Bracket
42 5825-09372-00
#6 Solder Lug, Bent
10 20-10291-15
Hose Clamp
43 4506-01106-24B SSS, 6-32 x
H/2"
11 04-10440
Ropelight Assembly
44 23-6534-16
Rubber Edge Prot.,
3-5/8"
12 H-20926
Insert Cable
45 23-6534-15
Rubber Edge Prot. 14"
13 03-7066-5
Coil Tubing
46 4008-01168-06
Mach. Screw, 8-32 x 3/8"
14 11-1324
Insert Panel
47 4008-01168-08
Mach. Screw, 8-32 x
W'
15 04-10430-1
Mirror Assembly
48 4808-01175-08
E-P #8 x
W'
Ind.
16 04-10430-2
Mirror Assembly
49 20-10301
Level Switch Assembly
17 04-10430-3
Mirror Assembly
50 03-9454
Cable Tie 4" Long
18 01-14322
Insert Frame, Lower
51 4008-01003-06
Mach. Screw, 8-32 x 3/8"
19 01-14321
Insert Frame, Upper
52 4010-01066-06
Cap Screw, 10-32 x 3/8"
20 01-14320-1
Insert Frame, Right
53 4701-00004-00
Lockwasher #10 Split
21 01-14320-2
Insert Frame, Left
54 H-20993
Token Switch Cable
22 20-10294
Speaker Hinge Panel
55 31-2561
Insert Overlay
23 01-7695-1
Solenoid Bracket
56 A-20889
6-Lamp PCB Assembly
24 A-12390
Flipper Stop Bracket
57 A-20909
48-Lamp PCB Assembly
25 31-2553
Screened Spkr. Panel Cover
58 4808-01175-16
E-P #8 x 1" Ind.
26 03-8265-3
Speaker Bracket Panel
59 03-9255-2
Spacer, #8 x .343"
27 01-13636
Display Shield
60 H-17609-5
Opto Cable, Square
28 H-20946.2
Insert Ground Cable
61 A-16908
RTV Opto LED Assembly
29 H-20940
Speaker Panel Cable
62 A-16909
RTV Opto Photo Trans. Assy.
30 03-7655-12
Cable Clamp, %"
63 4106-01013-06
Sh. Metal Screw, #6 x 3/8"
31 5901-12784-00
Dot Matrix Display Camp.
64 B-13826-3
Ground Lug Assy., 12"
32 5555-12924-00
Speaker 40, Tweeter 15w
65 03-7655-4
Cable Clamp, 14"
33 5555-12856-00
Speaker
5-1/4,
40, 25w
66 5070-09054-00
Diode 1N4004 1.0A.
2-32
