A-21 022
Shooter Lane Kicker Assembly
Item Part Number
1 04-10210.4
2 04-10211.5
3 04-10461
4 4010-01066-06
5 4701-00004-00
6 AE-23-S00
7 03-7066
S 01-S413
9 10-128
10 A-15847
11 4700-00104-00
12 12-6227
13 4006-01003-05
14 01-8600
15 5647-12693-65
16 4002-01105-0S
17 H-16437
18 5070-09054-00
19 H-19523
Description
Kicker Crank
Coil Mounting Bracket
Flipper Stop Bracket Assembly
Cap Screw, #10 x 3/S"
Lock Washer #10 Split
Coil Assembly
Coil Tubing
Coil Mounting Bracket
Spring
Flipper Link Assembly
Flat Washer, 23/64 x ~ x 169a.
Hair Pin Clip
Mach. Screw, 6-32 x 5/16"
Insulator
Mini-Micro Switch
Mach. Screw, 2-56 x
Y2"
Cable
Diode
Cable
2-28
