Item Part Number
Description
1 A-13500
Magnet Mounting Bracket
2 02-4446
Magnet Rod
3 B-13522
Magnet Coil
4 4423-01135-00
Jam Nut,
7/16-20
5 4701-00007-00
Lockwasher,
7/16"
(Split)
6 4705-00003-00
Spring Washer,
1/4
x
1/2
x 38ga.
Dlverter Assembly
pin
8-13496
Item Part Number
Description
1 B-13493
Mounting Bracket Assy
2 AE-24-900
Coil Assembly
3
A-10821
Flipper Stop Bracket Assy
4 03-7066
Coil Tubing
5 01-8413
Bracket Coil Tubing
6 4010-01008-06
Mach. Screw, 10-32 x 3/8
7 4701-00004-00
Lockwasher, #10 Split
Associated Parts
8 A-13494
Diverter Shaft & Paddle
a) 02-4444
Shaft
b) 03-8388
Diverter
c) 20-8716-1
Roll Pin, 3132 x
1/2
d) 20-8712-25
"poRing,
1/4"
Shaft
8
9 A-13278
Plunger Assembly
a) 02-4241
Coil Plunger
b) 10-389
Spring
c) 20-8712-43
"E"-Ring,
7/16"
Shaft
d) 20-8716-5
Roll Pin,
1/8
x
7/16
10 A-13279
Drive Arm Assembly
Magne;t
Assembly
pin
8-13520
ROLLERGAMES 63
