ROLLERGAMES 10
ROl.LERGAMES
GAME STATUS DISPLAYS (Continued)
Adjustment
Information-Ad
At end of the Audit Information presentation, with the AUTO-UP switch in the Up position, the operator can press
the ADVANCE button to proceed to the Adjustment Information portion of the ROLLERGAMES Game Status
Displays, as shown in the Player Score Displays. A list of the Game Adjustments appears in the ROLLER-
GAMES Game Adjustment
Table.
The operator can press the ADVANCE button once to view each Adjustment Information display item. To proceed
more rapidly through this information, the operator only has to press and hold the ADVANCE button. If a desired
item is passed, the operator can use the MANUAL-DOWN switch position with the ADVANCE button to back up
to the desired item.
The ROL.LE.RGAMES Game Adjustment Table lists the 70 items of the Adjustment Information portion of the
ROLlERGAMES Game Status Displays. Presentation of the displays is similarto that for the Audit Informa-
tion (that is, the upper display shows a descriptive phrase; the light type below the column headings names the
respective backbox displays where the information appears, etc.).
The ROlLERGAMES
Game-specific
Adjustments Table lists those game-specific Adjust-
ment Items for which settings vary between the major models of pinball products.
The Game Adjustment
Table, along with the Game-specific Adjustments Table, provides the Factory Settings for the three
major models of pinball
products (defined by country/language designation).
NOTE
In these tables, each Adjustment Item's Factory Setting for each of the three major models
of pinball products is that shown in the 'Domestic' (US / Can.) column, unless a supersed-
ing entry appears in the French or West German columns of these tables. A superseding
entry takes precedence over the 'Domestic' entry for the only the particular model indi-
cated.
RolierGames Game-specific Adjustments Table
Adjustment
Descriptive Phrase
Factory Setting
Item
Domestic
(Lower)
l{
Ger!
(Lower)
(Upper Display)
(US/Can.)
French uropean
Ad 31
Kickback Setting
Medium
32
Ex Ball Percent
30% 25% 30%
33
Pwr Play Ex Ball
7 Ramps
7 Ramps
35
Pwr Play Special
13 Ramps
15 Ramps
36
Top Drop Timer
Off
20 sec
38
Save Locks
Variable
Yes Variable
41
Spinner Timer
10 sec
9 sec
42
Roller Motion Free
1
0
48
Williams Restart
Willi
Wil
