A.S Printer Adjustments
(optional board required)
A.S 01 Column Width
The column width to be printed.
Range: 22 to 80.
A.S 02 Lines Per Page
The amount of lines per page.
Range: 20 to 80.
A.S 03 Pause Every Page
Choose whether the printer pauses at the end of a page.
YES The printer does pause.
NO The printer doesn't pause.
A.S 04 Printer Type
Select the type of printer: Parallel, Serial, ADP, Mini-Drucker, or NSM.
A.S OSSerial 8aud Rate
Select which baud rate to use for serial or ADP communications (bit rate):
300, 600, 1200,2400,
4800,
or
9600.
A.S 06 Serial D.T.R. (Data Terminal Ready)
When a serial printer is used, this line may be connected to a printer output line signaling that the
printer is busy.
NORMAL - Normal D.T.R. signal goes low to indicate the printer is not ready.
INVERTED - Inverted D.T.R. (busy) signal goes high to indicate the printer is not ready.
IGNORE D.T.R. signal is ignored.
A.S 08 Auto Printout
With the optional printer board installed, this adjustment allows the initiation of printouts
whenever the game detects a printer connected to the game. Parallel printers are detected
automatically by plugging them in and putting then on-line. Serial printers (or computers) are
detected by sending a carriage return (ASCII OxOD)or XON (ASCII
OX11).
This ad'
h h f
II .
uustment
as teo
owmq
settinqs:
OFF
Disable automatic printouts
MAIN AUDITS
Main Audit Table (8.1)
EARNINGS
Earning Audits (8.2)
STD. AUDITS
Standard Audits (8.3)
FEATURES
Feature Audits (8.4)
HISTOGRAMS Histograms (8.S)
TIMESTAMPS Time Stamps (8.6)
ALL DATA
All of the above data
The table specified above will automatically be printed when a printer (or computer) is detected.
1-38
