T.12 Flipper Coil Test Continued ...
Stop: The Stop mode halts the Flipper Coil Test. Press Enter during the Repeat mode
and the test stops. No coils should be activated while the test is stopped. Either press
the Escape button to return to the Test Menu, or the Enter button to move to the next
mode.
Run: The Run mode cycles through the flippers automatically. The display shows the
name and number of the flipper coil currently being pulsed.
T.13 Ordered Lamps Test
The number assigned to each lamp indicates the lamp's position in the matrix. The number on
the left indicates the column. The number on the right indicates the row. Example - Lamp 23
means 2nd column, 3rd row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through the
lamps. Lamps light in a clock-wise or counter clock-wise direction starting from the bottom of the
playfield. Direction depends on which button, Up or Down, is pressed. For each name and
number that is shown in the display the corresponding lamp should light. Any other results
indicates the system has detected a problem.
T.14 Lamp Row-Col
This test allows individual rows and columns in the lamp matrix to be operated. This is useful for
trouble-shooting wiring and driver problems.
Press the Up and Down buttons to cycles through the different rows and columns.
T.15 DIP Switch Test
This test is used to show the positions of the DIP switches on the CPU board (U27).
T.16 Dozer Test
This allows the operator to run the bulldozer motor and shows the status of two switches.
T.17 "TED" Test
This test activates each of Ted's coils. The status of the coils is shown in the displays.
T.18 "RED" Test
This test activates each of ~ed's coils. The status of the coils is shown in the displays.
T.19 Motor/Switch
This test runs all motors in the game, one at a time. At the same time, the switch matrix is
displayed. The operator can see if erroneous switch closures occur while the motors are on.
T.20 Empty Balls
This test kicks out all balls from all devices.
1-17
