RAISING
THE-
PLAYFIELD
&
CAUTION
Do not raise the playfield straight up! This game uses a slide assembly to raise and lower the
playfield.
To raise the playfield.
1.Grasp bottom arch and carefully lift up
playfield only high enough to clear safety
brackets. Rear guide legs should not hit wood
guide rails or be used to slide out playfield.
Rear Guide Leg
(2 used)
2.Pull the playfield out toward you until it stops
(rest position) and raise it approximately 3".
Be sure playfield is in locked position and
does not slide back into the cabinet. If it
does, repeat Step 2 before proceeding to
Step 3.
3.Rotate playfield to upright service position
(lean on backbox) by pulling toward you and
up. Listen for the sound of a click; this insures
locking and pivoting sequence.
To lower the playfield.
4.Rotate the playfield to the rest position. This
unlocks the pivoting mechanism.
5.Push back playfield into cabinet and into
playing position.
Slide Mechanism
(2 used)
1-5
Bottom Arch
CD
I
Wood Guide Roil
(2 used)
:::::::::::=:::J
~ Pivot Mechanism
1
(2 cssd)
