Lamp Assembly
Bulb Type
Bulb
Socket
Description
Number Part Number
Part Number
Part Number
11A Not Used
Not Used
Not Used
Not Used
NOT USED
12A Not Used
Not Used
Not Used
Not Used
NOT USED
13A 20-10696
Not Sold Separate Not Sold Separate Not Sold Separate START BUTTON
14A Not Used
Not Used
Not Used
Not Used
NOT USED
15A A-17835
#44
24-6549
Not Sold Separate RIGHT TOP LANE
16A A-17807
#44
24-6549
Not Sold Separate LEFT TOP LANE
17A A-17807
#44
24-6459
Not Sold Separate MARTIAN TARGET 4 (CENTER)
18A A-17835
#44
24-6549
Not Sold Separate CENTER LOOP ARROW
21A Not Used
Not Used
Not Used
Not Used
TICKETS LON
22A Not Used
Not Used
Not Used
Not Used
NOT USED
23A 20-10692-1
Not Sold Separate Not Sold Separate Not Sold Separate LAUNCH BUTTON
24A Not Sold Separate Not Sold Separate Not Sold Separate Not Sold Separate COIN DOOR ILLUMINATION
25A A-17807
#44
24-6549
Not Sold Separate MOTHERSHIP MULTIBAlL (RIGHT)
26A A-17807
#44
24-6549
Not Sold Separate MOTHERSHIP MULTIBALL (LEFT)
27A A-17835
#44
24-6549
Not Sold Separate LEFT RETURN LANE
28A A-17807
#44
24-6549
Not Sold Separate LEFT OUTLANE
31A Not Used
Not Used
Not Used
Not Used
NOT USED
32A Not Used
Not Used
Not Used
Not Used
NOT USED
33A Not Used
Not Used
Not Used
Not Used
NOT USED
34A Not Used
Not Used
Not Used
Not Used
NOT USED
35A A-17B07
#44
24-6549
Not Sold Separate LEFT DRAIN TO TROUGH
36A A-17807
#44
24-6549
Not Sold Separate RIGHT DRAIN TO TROUGH
':f1A A-17835
#44
24-6549
Not Sold Separate RIGHT RETURN LANE
38A A-17835
#44
24-6549
Not Sold Separate RIGHT OUTLANE
41A 04-12613
#555
24-8768
24-8767
RIGHT POPPER ARRON
42A 04-12613
#555
24-8768
24-8767
EXTRA BAlL
43A 04-12613
#555
24-8768
24-8767
MARTIAN ATTACK
44A 04-12613
#555
24-8768
24-8767
STROKE OF LUCK
45A 04-11037-8
#555
24-8768
Not Sold Separate LEFT SIDE SPOnlGHT
46A A-17807
#44
24-6549
Not Sold Separate CENTER ARROW
47A . A-23163
#44
24-6549
Not Sold Separate RIGHT MARTIAN (HIGH)
48A A-23163
#44
24-6549
Not Sold Separate RIGHT MARTIAN (LOW)
51A 04-12613
#555
24-8768
24-8767
MULTlBAlL
52A 04-12613
#555
24-8768
24-8767
CAPTURE 2
53A 04-12613
#555
24-8768
24-8767
CAPTURE 1
54A 04-12613
#555
24-8768
24-8767
CATURE ZONE ACTIVE
55A A-17807
#44
24-6549
Not Sold Separate SHOOT AGAIN
56A A-23163
#44
24-6549
Not Sold Separate BEHIND CENTER TARGETS
57A A-23163
#44
24-6549
Not Sold Separate UPPER RIGHT CORNER (MIDDLE)
58A Not Used
Not Used
Not Used
Not Used
NOT USED
61A A-23163
#44
24-6549
Not Sold Separate SHOOTER LANE 9 (TOP)
62A A-23163
#44
24-6549
Not Sold Separate UNDER RIGHT RAMP (LOW)
63A A-23163
#44
24-6549
Not Sold Separate UNDER RIGHT RAMP (HIGH)
64A A-23163
#44
24-6549
Not Sold Separate UPPER RIGHT CORNER (LOW)
65A A-23163
#44
24-6549
Not Sold Separate RIGHT ARCH (RIGHT)
66A A-23164
#44
24-6549
Not Sold
RIGHT ARCH (LEFT)
filA
A-23163
#44
24-6549
Not Sold Separate LEFT ARCH (RIGHT)
68A A-23163
#44
24-6549
Not Sold Separate LEFT ARCH (LEFT)
71A A-23163
#44
24-6549
Not Sold Separate LEFT SIDE 1 (BOTTOM)
72A A-23163
#44
24-6549
Not Sold Separate LEFT SIDE 2
73A A-23163
#44
24-6549
Not Sold Separate LEFT SIDE 3
74A A-23163
#44
24-6549
Not Sold Separate LEFT SIDE 4 (TOP)
75A A-23163
#44
24-6549
Not Sold Separate UNDER LEFT RAMP (BOTTOM)
76A A-23163
#44
24-6549
Not Sold Separate UNDER LEFT RAMP (TOP)
77A A-23163
#44
24-6549
Not Sold Separate BElWEEN LEFT & BOTTOM JETS
78A A-23163
#44
24-6549
Not Sold Separate UPPER LEFT CORNER
81A A-23163
#44
24-6549
Not Sold Separate RIGHT SLINGSHOT (BOTTOM)
82A A-23163
144
24-6549
Not Sold Separate RIGHT SLINGSHOT (SAUCER)
83A A-23163
#44
24-6549
Not Sold
RIGHT RETURN LANE (RIGHT)
84A A-23163
#44
24-6549
Not Sold Separate RIGHT RETURN LANE (LEFT)
85A A-23163
#44
24-6549
Not Sold Separate LEFT RETURN LANE (RIGHT)
86A A-23163
#44
24-6549
Not Sold Separate LEFT RETURN LANE (LEFT)
87A A-23163
#44
24-6549
Not Sold Separate LEFT SLINGSHOT (SAUCER)
88A A-23163
#44
24-6549
Not Sold Separate LEFT SLINGSHOT (BOTTOM)
Lamp Matrix A Locations
2-39
