UNIQUE
IP@I!.O©I§ IF@O©I§
PARTS LIST
•
For your information, the parts listed below are parts that are
u.nigu,e.
to the ~[l©[!£ ~~
game. This
data is provided as part of our ongoing program of providing as much information as we can about the
products of Williams Electronics Games.
(NOTE: In some instances, the parts are not available as individual items, because they are integral parts
of assemblies, or they are raw materials from which other parts are fabricated during the manufacturing
process.)
•
Pan
No.
Description
Part
No.
Description
A-12782
Switch Gate Assy - Outer
0·12768·573 Bottom Arch Assy
A-12783
Switch Gate Assy - Inner
0·12786
Inner Ramp Assy
A-12961-L
Micro Sw Assy - Car
0:12822
Back Panel Assy
A-12961-R Micro Sw Assy - Car
R·12787
Outer Ramp Assy
8-12785
Tgt OPIO Switch Assy
B-12800
Traverse Bracket Assy
RM- 27-02 Cable Cover, P Car
B-12803
Idler Pulley Assy
8-12805
Police Car Assy
01-9283
Light Mounting Bracket
B-12806
Car Motor Bracket
B-12807
Ball C/Wi re Assy
02-4252-29 F-F Spacer,
1-13/16"
B·12823
Ball Guide Assy
02-4252-30 F-F Spacer,
1-7/8"
B-12824
Ball Guide Assy
B-12825
Ball Guide Assy
11-573-PL Wood Playfield
B·12826
Ball Guide Assy
11-831-573 Wood Back Panel
8-12977
Playfield Plastic Assy
11-899-573 Cabinet· POLICE FORCE
B-12978
Playfield Plastic Assy
11-912-A Wood Rail,
37-7/8
8-9361·R·8 Ball Eject Assy
11·912-8
Wood Rail,
37-7/8
11-912-0
Wood Rail,
20-1/4
C-12827
Ball Guide Assembly
11·915
Wood Speaker Box
•
•
•
•
•
