COIN DOOR ASSEMBLY
2-Chute Door - 09·17002-x
•
3-Chute Door- 09-17003-x
("x" is the country designator)
Item Part Number
Description
Quantity
1 27·1038
Button Cover
2 or 3
2 27-1041·1-49
Price Panel
20r3
3 27-1026-1-15
Coin Entry Plate
2or3
4 27-1016
Lock Assembly
1
5 27-1061
Coin Return - Bezel
1
6 27-1062
Coin Return Flap
1
..
7 27-1021
Button Housing· 2-slot
1
27-1022
Button Housing· 3-slot
8 27-1111
Interlock Switch
9 27-1006
Coin Door. 2-5101
1
27-1007
Coin Door. 3-Slot
1
10 27·1005
Coin Door Frame
1
11 27·1003
WC
Screw. 6-32 x 3116
4
12 27-1008
Diagnostic Switch
1
13 27-1101
WC
Screw, 4-40 x
1/4
2
14 27-1102
Bracket, Diagnostic Switch
1
15 27-1037
Button
2 or 3
16 27-1078
WC
Screw. 6-32 x
3/8
2 or 3
17 27-1039
Conical Spring
2or3
18 27-1079
Self-lapping Screw. #6 x
1/4
2
19 27-1077
Coinbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
WC
Screw, 4-40 x 112
2
•
22 27-1017
Nut (key)
1
23 27-1012
Locking Cam
1
24 27·1011
Locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
WC
Screw
1
28 27-1089
R-Ring
1
29 27-1083
Retainer
1
30 27-1081
Coin Inlet Chute
2 or3
31 27-1088
Wire Clamp
20r3
32 27-1025
Key Hook
2 or 3
33 27-1086
Washer, #6
2 or 3
34
27-1078
WC
Screw. 6-32 x
3/8
20r3
27-1078
WC
Screw, 6-32 x
7/8
2 or 3
35 27-1079
Self·tapping Screw, #6 x
1/4
2or3
36
27-1084
Lamp Sockel
20r 3
27-1085
Lamp
20r 3
37 27-1096
Self-tapping Screw. #5 x
3/8
20r3
!
38 27-1087
M/C
Screw. 6-32 x
5/8
20r 3
39 27-1082
Lever Arm
2 or 3
40 27-1097
Switch Cover
2 or 3
41 27-1091
Coin Accept Chute
2 or 3
42 27-1075
Wire Form
2 or 3
27-1093
Wire Form
20r 3
43 27-1094
WC
Screw, 6·40 x
7/8
2
44 27-1087
WC
Screw. 6-32 x
5/8
2
45 27-1086
Washer, #6
2
46 27-1095
Nut. 4-40
2
•
47 27-1076
Coin Return Box
1
48 27·1078
we
Screw, 6-32 x
3/8
2
49 27-1092
Microswitch
2 or3
