INNER RAMP ASSEMBLY
0-12786
•
Item Part Number
Description
Item Part Number
Description
1 A-12239
Sub-Mini Switch Assy
16
07-66BB-16N
Rivet - Nickel Plate,
1f8
x
liS
2 A-12558
Switch Gate Assembly
17 07-6688-20N
Rivet - Nickel Plate,
1/8
x
1/4
3 A-12783
Switch Gate Assy-Inner
18 31-1006-573-12 Playfield Plastic
4
A-12976
PVPlas Bracket Assy
19 31-1006-573-13 Playfiald Plastic
5 8-12156
Single Flash lamp Assy
20 31-1498-573-0
Dacal- Ramp
6 H-12967
Flasher, Switch Cable
21 31-1498-573-E Decal-Ramp
7 01-8774
Switch Bracket
22 31-1498-573-G Dacal· Ramp
8 01-8795
Ramp Flap
23 4002-01005-06
Mach. Screw, 2-56 x
3/8
9
01-9187
Bracket - Ball Deflect
24 4006-01005-08
Mach. Screw, 6-32 x
1/2
10 03-7520-2
Nylon, Ty - Wrap
25 4006-01005-28
Mach. Screw, 6-32 x
1-3/4
11 03-8022·3
Spacer.I-11/64lg
26 4106-01022·12
Sh. Metal Screw, #6 x
3/4
12 03-8022-4
Spacer.
1/4lg
27 4106-01033-08
Sh. Melal Screw, #6 x
1/2
13
03-8022-5
Spacer.
11132
Lg
28 4406-01128-00
NUl, 6-32 KEPS
14 03-8149-9
Mini Dome - Trans. Rad
29 4700-00003-00
Flatwasher,
1/8x9/32x21
gao
15 03-8263
Ramp -Inner
30 4701-00024-00
lockwasher, #2 Split
OUTER RAMP ASSEMBLY
R-12787
item Part Number
Description
Item Part Number
Description
1
A-12782
Switch Gate Assy- Outer
19 07 -6688-18N
Rivet.,
1/8
x
3/16
2
A-7438-1
Terminal Strip Assembly
20 07-6688-20N
Aivet Nickel Plate, 1/8 x
1/4
•
3 C-12689
s-Pes lite Socket Assy
21 31-1006·573-21 Playfield Plastic
4 H-12969
Skill Shot Cable
22 31-1006A-573-2 Playlield Plastic
5 H-12972
Aux Car Cable
23 31-1497 -573-A Decal- Ramp
6 01-8641
Microswitch Mig. Bracket
24 31-1497-573-6
Dacal- Ramp
7 01·8710
AampFlap
25 31-1497·573-C
Decat-Ramo
8 01·8947
WlAamp Holding Bracket
26 31-1498-573-F
Decal- Ramp
9 01·9188
Bracket - Mid Ramp
27 31-1498-573-L
Dscal- Ramp
10 01·9189
Bracket - End Ramp
28 4004-01003-10
Mach. Screw, 4-40 x
5/8
11 01-9196
Light Shield Socket
29 4006·01005-08
Mach. Screw. 6-32 x
1/2
12 01-9264
Bracket Car Guida
30 4106-01022-12
Sh. Metal Screw, #6 x 3/4
13 03·7520-2
Nylon, Ty-Wrap
31 4108-01001-20
Sh. Metal Screw, #8 x
1-1/4
14 03-8022-4
Spacer,
1/4"
Lg.
32 4406·01128·00
Nut, 6·32 KEPS
15 03-8069-2
Light Shield - Double
33 4700-00003-00
Flatwasher,1/8x 9132x21 gao
16 03-8264
Ramp· Outer
34 5070-06258-00
Diode, 1N4001, 1.0 A.
17 03-8285-1
Plastic Grommet
35 5647-12133-04
Microswitch
18 07 -66S8-16N Rivet,
1/8
x
1/8
•
•
•
