JET BUMPER ASSEMBLY
B-9414 ..1
Item Part Number
1 A-4754
2 03-6009-AS
3 03-6035-1
4 03-7443-5
5 10-7
6 A-11199
a) 24-8768
b) 24-8776
7 03-8254-6
Description
Bumper Ring Assy
Bumper Base-Wht
Bumper Wafer-Blue
Bumper Body-Wht
Spring-Jet Bumper
Socket & Bulb Assy
Bulb #555, (6.3V, .2SA.)
Wedge Base Socket
Jet Cap - Yellow
JET BUMPER COil ASSY
B-9415-1
Item Part Number
Description
1 8-7417
Bracket & Stop Assy
2 01-1747
Coil Retaining Bracket
3 01-5492
Armature Link, Steel
4 01-5493
Armature Link, Bakelite
5 02-3406-1
Coil Plunger
6
10-326
Armature Spring
7 AE-23-800
Coil Assembly
8 4006-01017 -04 Mach. Screw, 6-32
x
1/4
9 03-7066
Coil Tubing
ASSOCIATEP PARTS
8-12030-2
B-12029-2
SW-11A-37
01-1168
01-3670
03-7395
4005-01051-12
4405-01117-00
5070-06258-00
Jet Bumper Sw & Diode Assy
Jet Bumper Sw & Brkt. ASsy
Jet Bumper Switch Assy
Mounting Brkt., Bumper Sw
Switch Plate - Curved
Switch Actuator
Mach. Screw, 5-40
x
3/4
Nut, 5-40 Hex.
Diode, 1N4001, 1.0 A.
JET BUMPER ASSEMBLY
JET BUMPER COIL ASSEMBLY
•
•
•
