U.908 INSTALL ADD-A-BALL
This option deletes all Free Play awards and replaces them with Extra Ball awards. Individual
adjustments are affected, as follows:
Adjust.
Name
New Settings
A.113 Replay Boost
Off
A.114 Replay Award
Extra Ball
A.115 Special Award
Extra Ball
A.1 17 Extra Ball Ticket
No
A.119 Match Feature
Off
A.4 04 Champion Credits
00
A.4 05 High Score 1 Credits
00
A.406 High Score 2 Credits
00
A.4 07 High Score 3 Credits
00
A.4 08 High Score 4 Credits
00
U.9 09 INSTALL TICKET
This option deletes Credit awards and replaces them with Ticket awards. Individual adjustments
are affected as follows:
Adiust.
Name
New Settin_g_s
A.1 14 Replay Award
Ticket
A.1 15 Special Award
Ticket
A.116 Match Award
Ticket
A.117 Extra Ball Ticket
Yes
A.131 Ticket Expansion Brd.
Yes
A.4 02 H.S.T.D. Award Ticket
Yes
U.910 INSTALL NOVELTY
This option removes all Free Play and Extra Ball awards. Individual adjustments are affected as
follows:
Adjust.
Name
New Settil'lQ_s
A.104 Maximum Extra Ball
Off
A.105 Replay system
Fixed
A.109 Replay Level 1
Off
A.110 Replay Level 2
Off
A.111 Replay Level 3
Off
A.112 R~lay Level 4
Off
A.1 15 Special Award
Points
A.1 19 Match Feature
Off
A.401 Highest Score
On
A.4 04 Champion Credit
00
A.405 High Score 1 Credits
00
A.406 High Score 2 Credits
00
A.407 Hiqh Score 3 Credits
00
A.408 High Score 4 Credits
00
U.911 NOT USED
U.912 SERIAL CAPTURE
This sets up the printer adjustments for a serial transmission to a laptop computer, (9600 baud,
40 column, no page breaks, serial printer). This option requires the installation of the optional
printer kit; part number 63110.
U.913 TO U.916 NOT USED
1-22
