T.6 GENERAL ILLUMINATION TEST CONTINUED ...
Run: The Run mode cycles through the General Illumination test automatically. For
each circuit shown in the display the corresponding bulbs should light. If any other
results occur, the system has detected a problem. To retum to the Test menu, press the
Escape button. To return to the Stop mode, press the Enter button.
T.7 SOUNDAND MUSICTEST
The Sound and Music test checks the audio circuits. This test has three modes for testing the
sound and music circuits -- Run, Repeat, and Stop.
Run: The Run mode steps through a sequence of sounds and music. Press the Up or
Down buttons to advance to a particular sound or tune. A sound or tune should be heard
for each name and number that appears in the display. Any other results indicate the
system has detected a problem. To return to the Test menu, press the Escape button.
To advance to the next test mode, press the Enter button.
Repeat:
The Repeat mode causes the program to stop and repeat a particular
sound/tune. The same sound repeats continuously until you press the Up or Down
buttons to advance to the next one. Any other results indicates the system has detected
a problem. To return to the Test menu, press the Escape button. To advance to the next
test mode, press the Enter button.
Stop: The Stop mode stops this test altogether. Nothing should be heard. Any other
results indicate the system has detected a problem. To return to the Test menu, press
the Escape button. To return to the Run mode, press the Enter button.
T.8 SINGLE LAMP TEST
The number assigned to each lamp indicates the lamp's position in the matrix. The number on
the left indicates the column. The number on the right indicates the row. Example - Lamp 23
means 2nd column, 3rd row.
The Single Lamp test checks each lamp circuit individually. Press the Up or Down buttons to
scroll through this test. A lamp should light for each name and number that is displayed. Any
other results indicate the system has detected a problem. To return to the Test menu, press the
Escape button.
T.9 ALL LAMPS TEST
This test causes all the controlled lamps to flash at the same time. Every controlled lamp should
flash. Any other results indicate the system has detected a problem. To return to the Test menu,
press the Escape button.
T.10 LAMP AND FLASHERTEST
This test causes all the flashlamps and the controlled lamps to flash at the same time. The
controlled lamps blink, while the flashlamps cycle from highest to lowest. Any other results
indicate the system has detected a problem. To return to the Test menu, press the Escape
button.
T.11 DISPLAY TEST
This test automatically checks every dot in the Dot Matrix Display board. A series of patterns
appear in sequence. Each pattern tums on and off a section of dots. Every dot on the matrix
display should be turned on and off during this test. To return to the Test menu, press the
Escape button.
1-17
