Item Part Number Description
0
1 A-6306-2
Bell Armature Assembly
2 A-14526
Kicker Mounting Bracket Assy.
3 01-8-508-T
Solenoid Bracket
4 10-135
Solenoid Spring
5 23-6420
Rubber Grommet
6 AE-23-800
Coil Assembly
7 03-7067-5
Coil Tubing
8 4008-01017-04 Mach. Screw, #8-32 x 1/4"
9
03-8523
Insulator
A-14525
Kicker Bracket Assembly
B-11873
Bottom Arch Kicker Assembly
Item Part Number Description
1 A-6306-2
Bell Armature Assembly
2 AE-23-800
Coil Sub-Assembly
2
3 01-11273
Mounting Bracket
4
01-8-508-T
Solenoid Bracket
5 03-7067-5
Coil Tubing
6 10-135
Solenoid Spring
7 23-6420
Rubber Grommet
8
4008-01017-04 Mach. Screw, 8-32 x 1/4"
9
03-8523
Insulator
(]\
2-23
