Flipper Cabinet Switch Circuits
3-13
Flipper Opto Board
3-14
Outhole Trough Block Diagram
3-15
Trough 71R LED Board
3-16
Trough 7 IR Photo Transistor Board
3-17
Single LED and Photo Transistor Boards and Typical Circuit Diagram
3-18
16-0pto Switch Circuit Block Diagram
3-19
16-0pto Switch Board Assembly
3-20
16-0pto Switch Board Schematic
3-21
Coin Door Interface Board Assembly
3-22
Coin Door Interface Board Schematic
3-23
Security CPU Board Interboard Wiring List...
3-24
Sound Board Interboard Wiring List...
3-25
Speaker Wiring Diagram
3-25
Dot Matrix Controller Board Interboard Wiring List..
3-26
Fliptronic II Board Interboard Wiring List..
3-27
Power Driver Board Interboard Wiring List..
3-28
