SKULL ASSEMBLY
1) The Skull Assembly is in two pieces: the upper part is the face and the lower part is the base. The
base contains the lower jaw.
2) To remove the face, unscrew the small Phillips screw located at the top middle of the skull forehead.
Carefully, stretch the right side of the face and pull it off of the base first, then do the same to the left
side. When re-attaching the face, snap the left side on first, then the right side.
Do not stretch both
sides of the face at the same time, or the eyes will pop out.
3) The four bulbs are now accessible. This assembly uses two #906 bulbs (large bulbs), and two #44
bulbs (small bulbs).
4) To remove the base from the playfield, raise the playfield and unplug the connector going to the Skull
Assembly. Lower the pfaytield.
5) Remove the two hex head screws that hold the base to the playfield.
6) The front of the base is held down by a tab that slides into a slot in a metal bracket. Slide the base
back so that the tab clears the slot.
7) Lift the base off of the playfield.
PHILLIPS SCREW
FRONT VIEW
HEX HEAD SCREWS
<.
CONNECTO;:;
SIDE VIEW
TOP VEW
1-48
