Fliptronic II Board Assembly
A-15472-1
J
,!
00000000
H
oiiJ
13
J902
J905-1
J905-2
J905-3
J905-4
J905-5
J905-6
J903
J901-1
J901-2
J901-3
J901-4
J901-5
White-Blue, 50Vac from Power Drvr Brd J 104-2
White-Blue, 50Vac loop from J901-1
White-Blue, 50Vac from Power Drvr Brd J104-1
Key
White-Blue, 50Vac loop from J901-3
8
0
a;
0
o
o
c
o '"
Blue-Violet, F2 to right flipper opto J 1-2
Blue-Gray, F4 to left flipper opto J1-2
Black-Yellow, F6 to right flipper opto J1-1
Key
Black-Blue, F8 to left flipper opto J1-1 (not used)
Orange, ground to lett flipper opto J 1-4
J906-1 Black-Green, F1 to lower right E.O.S. switch
J906-2 Key
J906-3 Black-Blue, F3 to lower lett E.O.S. switch
J906-4 Black-Violet, F5 to upper right E.O.S. switch
J906-5
N/C
J906-6 Orange, ground to E.O.S. switches
J907-1 Red-Green, +50V to lower right flipper coil
J907-2 Red-Green, +50V loop from J907-1
J907-3 Key
J907-4 Red-Blue, +50V to lower left flipper coil
J907-5 Red-Blue, +50V loop from J907-4
J907-6 Red-Violet, +50V to upper right flipper coil
J907-7 Red-Violet, +50V loop from J907-6
J907-8
N/C
J907-9
N/C
3-27
J902-1
N/C
J902-2
N/C
J902-3
N/C
J902-4 Orange-Violet, holding, upper right flipper coil
J902-5 N/C
J902-6 Yellow-Violet, power, upper right flipper coil
J902-7 Orange-Blue, holding, lower lett flipper coil
J902-8
N/C
J902-9 Yellow-Blue, power, lower left flipper coil
J902-10 Key
J902-11 Orange-Green, holding, lower right flipper coil
J902-12 N/C
J902-13 Yellow-Green, power, lower right flipper coil
J903, 34-pin ribbon cable, data to/from J202: J601: P1
J904-1 Gray, +5V from Power Driver Board J114-3, 4
J904-2 Gray-Green, +12V from Pwr Drvr Brd J 114-1,2
J904-3 Key
J904-4 Black, ground from Power Driver Brd J114-5, 7
J904-5 Black ,ground from Power Driver Brd J 114-5, 7
