Security CPU Board Assembly
A-17651-50025
'1
000 "00""""""0
1
26
0 I
' ~O[][H)(I')[J[l[l[HJI
J
25
J201
o
G
!
I
.___ _ _ j
,212
J20B
J206
ro-o~.ooooj
r;.oooooool
~~-o-oj
6
1 9
1 9
1
nos
J2D7
J209
L_E;f~ .~~ ~~
112
t
9
t
9
I
J201,
26-pin ribbon cable, data to/from J602
J202,
34-pin ribbon cable, data to/from J903;
Pt:
J601
J203- Not Used
J204- Not Used
J205-1 Orange-Brown, ded. sw. row 1, to Coin Door Srd Jl-8
J205-2 Orange-Red, ded. sw. row 2, to Coin Door Brd Jl-7
J205-3 Orange-Black, ded. sw. row 3, to Coin Door Brd J 1-6
J205-4 Orange-Yellow, ded. sw. row 4, to Coin Door Brd Jl-5
J205-5 Key
J205-6 Orange-Green, ded. sw. row 5, to Coin Door Brd Jl-4
J205-7 Orange-Blue, ded. sw. row 6, to Coin Door Brd Jl-3
J205-8 Orange-Violet, ded. sw. row 7, to Coin Door Srd Jl-2
J205-9 Orange-Gray, ded. sw. row 8, to Coin Door Brd J1-1
J205-10 Black, ground, to Coin Door Srd J 1-10
J205-11
N/C
J205-12 Orange-White, switch enable, to Coin Door Brd Jl-11
J206- Not Used
J207-1 Green-Brown, switch column 1, to playfield switches
J207-2 Green-Red, switch column 2, to playfield switches
J207-3 Green-Orange, switch column 3, to playfield switches
J207-4 Green-Yellow, switch column 4, to playfield switches
J207-5 Green-Black, switch column 5, to playfield switches
J207-6 Green-Blue, switch column 6, to playfield switches
J207-7 N\C
J207-8 Key
J207-9
N/C
J207-10 NlC
J207-11 NlC
J208- Not Used
J209-1 White-Brown, switch row 1, to playfield switches
J209-2 White-Red, switch row
2,
to playtield switches
J209-3 White-Orange, switch row 3, to playfield switches
J209-4 White-Yellow, switch row 4, to playfield switches
J209-5 White-Green, switch row 5, to playfield switches
J209-6 Key
J209-7 White-Blue, switch row 6, to playfield switches
J209-8 White-Violet, switch row 7, to playfield switches
J209-9 White-Gray, switch row 8, to playfield switches
J210-1 Black, ground, from Power Driver Board J114-5,7
J210-2 Key
J210-3 Black, ground, from Power Driver Board J114-5, 7
J210-4 Gray, +5V, from Power Driver Board J114-3, 4
J210-5 Gray, +5V, from Power Driver Board J114-3, 4
J210-6 Gray-Green, +12V, from Power Driver Board J114-1, 2
J210-7 Gray-Green, +12V, from Power Driver Board J114-1, 2
J211,
34-pin ribbon cable, data to/from J 113
J212-1 Green-Brown, switch col. 1, to Coin Door Board J3-1
J212-2 Green-Red, switch col. 2, to Coin Door Board J3-2
J212-3 N/C
J212-4 White-Brown, switch row 1, to Coin Door Board J3-3
J212-5 Key
J212-6 White-Red, switch row 2, to Coin Door Board J3-4
J212-7 White-Orange, switch row 3, to Coin Door Board J3-5
J212-8 White-Yellow, switch row 4, to Coin Door Board J3-6
J213-1 Black, to battery holder board
J
1-1
J21 3-2 Black, to battery holder board J 1-2
J213-3 Key
J213-4
Gray,
to battery holder board Jl-4
J213-5 Gray, to battery holder board J 1-5
Jl-1
Jl-2
Jl-3
Jl-4
Jl-5
Black, from CPU J213-1
Black, from CPU J213-2
Key
Gray, from CPU J21 3-4
Gray, from CPU J213·5
I
I
3-24
