Lower Playfield Parts
Item Part Number Description
f1
t't
.3
1 01-9211
Plfd. Hanger Brack,et Assy. (2)
0
2 01-11781
Leg Support (2)
3 A-19963
Outhole Ball Trough Assy.
4 A-14876-R-3 Flipper Assembly, Lwr. Right
5 A-15849-L -2 Flipper Assembly, Lwr. Left
6 A-17223
ts-opto
PCB
&
Bracket Assy.
7 A-20043
16-Lamp Board Assembly
8
A-17811
Kicker Arm (Slingshot) Assy.
B-9362-R-3
Coil
&
Bracket Assy., Right
9 A-20042
a-Lamp Board Assembly
10 A-19965
Ball Popper Assembly
11
A-19948
Underside Ball Trough Assy.
12 A-19945
Flipper Assembly, Upper Right
13 A-20181-1
Pivot Assembly, Right
14 A-20181-2
Pivot Assembly, Left
15 A-14615
t-Bank Drop Target Assembly
16 A-20041
12-Lamp PCB Assembly
17 A-20134
Eject Assembly
18 A-20044
8-Lamp Board Assembly
19 04-10084.1
Pin Plate Weldment
20 A-17811
Kicker Arm (Slingshot) Assy.
B-9362-L-2
Coil
&
Bracket Assy., Left
