XI. PARTS LIST
#1104-E MATA-HARI
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-125
Bulbs, #44
E-125-22
ASSEMBLY COILS
Chimes (4)
CN-31-2000
Coin Lockout
FO-36-7000
Flipper Left & Right (2)
AQ-25-500/
34-5050
Knocker .. '.'
_
AR-26-1200
Outhole Kicker
AN-26-1200
Saucer
AO-27 -1300
Thumper-Bumper (4)
AN-26-1200
Sling-Shot (2)
AN-26-1200
PLAYFIELD PARTS
See Figure II
Unit Coils
Drop Target (Reset) (2)
NO-26-1900
MODULES
Lamp Driver A5
AS-2518-23
Display Driver A1 (5 Used)
AS-2518-21
Solenoid Driver/Voltage Regulator A3
AS-2518-22
MPU A4
AS-2887-6
Transformer & Rectifier A2
AS-2877-1
Rectifier Board (Part of A2)
AS-2518-18
REPAIR PROCEDURES/ AIDS
Module
&
Component Replacement
FO. 560
AID (Assistance in Diagnostics)
Kit, used with FO. 560
KIT #485
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair.)
Kit #490-Rectifier
Board (Part of A2)
Kit #503-MPU Board A4 (Less Memory U1-U6)
Kit #492-Solenoid Driver/Voltage Regulator A3
Kit #493-Display Driver A1
Kit #494-Lamp Driver A5
