Power Driver Board Continued. ••
J114-1 Gray-Green, +12V to J21Q-6, 7; J904-2
J114-2 Gray-Green, +12V to J21 Q-6, 7; J904-2
J114-3 Gr~y, +5V to J210-4, 5; J3-1,3; J904-1
J114-4 Gray, +5V to J210-4, 5; J3-1 ,3; J904-1
J114-5 Black, ground to J21Q-1, 3; J3-4, 5; J904-4, 5
J114-6 Key
J 114-7 Black, ground to J21Q-1,3; J3-4, 5;. J904-4, 5
J115-1 Yellow-White, 6.8Vac from xformer secondary
J115-2 White-Brown, 6.8Vac from xformer secondary
J11S-3 White-Brown, 6.8Vac from xformer secondary
J11S-4 White-Orange, 6.8Vac from xformer secondary
J11S-5 White-Yellow, 6.8Vac from xformer secondary
J11S-6 White-Yellow, 6.8Vac from xformer secondary
J11S-7 Orange, 6.8Vac from xformer secondary
J11S-8 Orange, 6.8Vac from xformer secondary
J115-9 Key
J11S-10 Green, 6.8Vac from xformer secondary
J115-11 Brown, 6.8Vac from xformer secondary
J11S-12 Brown, 6.8Vac from xformer secondary
J116-1 Key
J116-2 Gray-Yellow, +12V to Coin Door Board J2-2
J 116-3 Black, ground to Coin Door Board J2-1
J116-4
N/C
J117-1 Key
J117-2 Gray-Yellow, +12V to Dot Matrix Cntrllr J606-7
J 117-3 Black, ground to Dot Matrix Cntrllr J606-3
J117-4 Gray, +SV to Dot Matrix Cntrllr J606-S
J118-1 Key
J118-2 Gray-Yellow, +12V to playfield boards
J118-3 Black, ground to playfield boards
J118-4
N/C
J119-1 White-Violet, 6.8Vac, G.I. to Coin Door BrdJ2-S
J119-2 Key
J 119-3 Violet, retum, GJ. to Coin Door Board J2-3
J12Q-1 Brown, retum, G.I. to insert panel
J120-2 Orange, retum, G.I. to insert panel
J12Q-3 Yellow, return, G.I. to insert panel
J12Q-4 Key
J120-5 Green, return, G.I. to insert panel
J12Q-6 Violet, return, GJ. to insert panel
J12Q-7 White-Brown,6.8Vac,
G.I. to insert panel
J12Q-8 White-Orange, 6.8Vac, G.I. to insert panel
J120-9 White-Yellow, 6.8Vac, G.I. to inSert panel
J12Q-10 White-Green, 6.8Vac, G.I. to insert panel
J12Q-11 White-Violet, 6.8Vac, G.I. to insert panel
J121-1 Brown, retum, G.I. to
J121-2 Orange, return, G.I. to playfield
J121-3 Yellow, return, GJ. to playfield
J121-4 Key
J121-5 Green, return, GJ. to insert panel
J121-S NlC
J121-7 White-Brown, 6.8Vac, G.I. to playfield
J121-8 White-Orange, 6.8Vac, GJ. to playfield
J121-9 White-Yellow, S.8Vac, G.I. to playfield
J121-10 White-Green, S.8Vac, G.I. to playfield
J121-11
N/C
J122-1 Blue-Brown, solenoid 25 drive to flashlamp
J122-2 Blue-Red, solenoid 26 drive to flash lamp
J122-3 Blue-Orange, solenoid 27 drive to flashlamp
J122-4 Blue-Yellow, solenoid 28 drive to flashlamp
J122-S
N/C
J122-6
N/C
J122-7 Key
J122-8
N/C
J122-9 NlC
J123- Not Used
J124- Not Used
J125- Not Used
J12S-1 Black-Brown, solenoid 17 drive to flash lamp
J126-2 Black-Red, solenoid 18 drive to flash lamp
J126-3 Black-Orange, solenoid 19 drive to flashlamp
J126-4 Black-Yellow, solenoid 20 drive to flash lamp
J12S-S Blue-Green, solenoid 21 drive to flashlamp
J12S-S Blue-Black, solenoid 22 drive to flashlamp
J126-7 Blue-Violet, solenoid 23 drive to flashlamp
J12S-8 Blue-Gray, solenoid 24 drive to flashlamp
J12S-9 Key
J126-10
N/C
J126-11 NlC
J126-12 NlC
J126-13 NlC
J127-1 Brown-Black, solenoid 9 drive to coil
J127-2 Key
J127-3 Brown-Red, solenoid 10 drive to coil
J127-4 Brown-Orange, solenoid 11 drive to coil
J127-S Brown-Yellow, solenoid 12 drive to coil
J127-6 Brown-Green, solenoid 13 drive to coil
J127-7 Brown-Blue, solenoid 14 drive to coil
J127-8 Brown-Violet, solenoid 15 drive to flashlamps
J127-9 Brown-Gray, solenoid 16 drive to flash lamps
J128-Not Used
J129-Not Used
J13Q-1 Violet-Brown, solenoid 1 drive to coil
J13Q-2 NlC
J13Q-3 Key
J 13Q-4 Violet-Qrange, solenoid 3 drive to coil
J13Q-5 Violet-Yellow, solenoid 4 drive to coil
J130-6 Violet-Green, solenoid 5 drive to coil
J13Q-7 Violet-Blue, solenoid 6 drive to coil
J 13Q-8 Violet-Black, solenoid 7 drive to coil
J13Q-9 Violet-Gray, solenoid 8 drive to coil
J131- Not Used
J132- Not Used
3-29
