Security CPU Board Assembly
A-17651-50051
~I
:::::::::=::::::I~
~I::::::::::::
I~:
0
J201
o
J202
o
o
m~
o
o
m
-
e;
~
o
o
o
...
I
I
-r
-
.
o
o
'"
I~==~I
I
I
J212
J208
J206
1000.00001 10.000000011000.000001
8
1 9
1 9
1
J205
J207
J209
~o.ooooooocol
~.ooooooollooo.oooool
12
t
9
1 9
1
J201,
2S-pin ribbon cable, data tolfrom J602
J202,
34-pin ribbon cable, data to/from J903; P1; JS01
J203- Not Used
J204- Not Used
J205-1 Orange-Brown, ded. sw. row 1, to Coin Door Brd J 1-8
J205-2 Orange-Red, ded. sw. row 2, to Coin Door Brd J1-7
J205-3 Orange-Black, ded. sw. row 3, to Coin Door Brd J1-6
J205-4 Orange-Yellow, ded. sw. row 4, to Coin Door Brd J1-5
J205-5 Key
J205-S Orange-Green, ded. sw. row 5, to Coin Door Brd J1-4
J205-7 Orange-Blue, ded. sw. row S, to Coin Door Brd J1-3
J205-8 Orange-Violet, ded. sw. row 7, to Coin Door Brd J1-2
J205-9 Orange-Gray, ded. sw. row 8, to Coin Door Brd J1-1
J205-1 0 Black, ground, to Coin Door Brd J1-10
J205-11 NlC
J205-12 Orange-White, switch enable, to Coin Door Brd J1-11
J206- Not Used
J207-1 Green-Brown, switch column 1, to playfield switches
J207-2 Green-Red, switch column 2, to playfield switches
J207-3 Green-Qrange, switch column 3, to playfield switches
J207-4 Green-Yellow, switch column 4, to playfield switches
J207-5 Green-Black, switch column 5, to playfield switches
J207-S Green-Blue, switch column S, to playfield switches
J207-7
NlC
J207-8 Key
J207-9 NlC
J207-10 NlC
J207-11 NlC
J208- Not Used
J209-1 White-Brown, switch row 1, to playfield switches
J209-2 White-Red, switch row 2, to playfield switches
J209-3 White-Orange, switch row 3, to playfield switches
J209-4 White-Yellow, switch row 4, to playfield switches
J209-5 White-Green, switch row 5, to playfield switches
J209-S Key
J209-7 White-Blue, switch row S, to playfield switches
J209-8 White-Violet, switch row 7, to playfield switches
J209-9 White-Gray, switch row 8, to playfield switches
J210-1 Black, ground, from Power Driver Board J114-5,7
J210-2 Key
J210-3 Black, ground, from Power Driver Board J114-5, 7
J210-4 Gray, +5V, from Power Driver Board J114-3, 4
J210-5 Gray, +5V, from Power Driver Board J114-3, 4
J210-S . Gray-Green, +12V, from Power Driver Board J114-1, 2
J210-7 Gray-Green, +12V, from Power Driver Board J114-1, 2
J211,
34-pin ribbon cable, data to/from J113
J212-1 Green-Brown, switch col. 1, to Coin Door Board J3-1
J212-2 Green-Red, switch col. 2, to Coin Door Board J3-2
J212-3 NlC
J212-4 White-Brown, switch row 1, to Coin Door Board J3-3
J212-5 Key
J212-6 White-Red, switch row 2, to Coin Door Board J3-4
J212-7 White-Orange, switch row 3, to Coin Door Board J3-5
J212-8 White-Yellow, switch row 4, to Coin Door Board J3-S
J213-1 Black, to battery holder board J1-1
J213-2 Black, to battery holder board J1-2
J213-3 Key
J213-4 Gray, to battery holder board J1-4
J213-5 Gray, to battery holder board J1-5
J1-1 Black, from CPU J213-1
J1-2 Black, from CPU J213-2
J1-3 Key
J1-4 Gray, from CPU J213-4
J1-5 Gray, from CPU J213-5
3-24
