C-111S9
Visor Assembly
Item Part Number
Description
Item Part Number
Description
1 C-11158
Visor Rivet Assembly
6 B-11555
Lever Arm
&
Link Assy (2)
2 01-8366
Pivot Bracket
7 02-4265
Connecting Pin (2)
3 02-4264
Hinge Pin
8 4700-00073-00
FW
9/32
x
1/2
x 21ga. (2)
4 20-8712-18
'E' Ring,
3116"
Shaft (2)
9 12-6227
Hair Pin Clip (2)
*5 31-2328-7
Decal
* Not available for individual sale. Order Decal Set31·2328.
C-111S7
Moving Target Assembly
Item Part Number
Description
Item Part Number
Description
10 B-11406
Guide & Carrier Assembly
15 C-11176
Switch
&
Cable Assembly
11 03-8028
Carrier Retainer (2)
16 01-3670-1
Switch Plate, Flat (5)
12 01-8494
Support Bracket (2)
17 4004-01003-12 MS-40 x 3/4 P-PH-S (10)
~
13 4106-01019-10 SMS #6 x
5/8
P-RH (4)
18 4404-01119-00 Nut 4-40 ESNA (1 0)
14 23-6534-9
Edge Protector (5)
19 03-7722-4
Kwik-Klip
A-20100
Visor Motor Bracket Assembly
Item Part Number
Description
Item Part Number
Description
20 01-13895
Motor Drive Bracket
28 4010-01044-04 MS 10-32 x 114 P-FH (2)
21 04-10080
Motor Cam Assembly
29 4008-01083-04 SS 8-32 x
1/4
SH-CP-N
22 04-10068
Adjustment Bracket Assy.
30 H-20127
UplDown Cable Assembly
23 14-8023
Visor Drive Motor
31 H-18600-3
Motor Cable Ass'y, 2 Pin
24 01-8600
Insulator (2)
32 5070-09054-00 Diode 1 N4004, 1.0 A (2)
25 4002-01105-07 MS 2-56 x
7/16
P-PH-S (4)
33 03-7722-4
Kwik-Klip (2)
26 4010-01007-16 MS 10-32 x 1 P-PH (2)
34 5647-12694-06 Mini Micro Switch (2)
27 4006-01003-04 MS 6-32 x
1/4
P-PH-S (2)
2-23
