A-14615 1-8ank Drop Target Assembly
@@
Item Part Number
Description
l!run
part Number
Description
1.
03-8033
Target - Flush
14.
03-8034
Single Stop Target
2.
A-14617
Bracket
&
Post Assy.
15.
4010-01025-14
Mach. Screw, 10-32 x
7/8"
3.
4408-0119-00
Nut 8-32 ESNA
16.
07-6688-17N
Rivet,
5/32
x
7/32
4.
A-11397
Stop Bracket Assembly
17.
10-433
Spring Extension
5.
AE-26-1200
Coil Assembly
18.
5070-09054-00
Diode 1N4001
6.
01-8413
Coil Mounting Bracket
19.
5647-12693-31
Switch
7.
03-7066-4
Tubing
20.
01-8600
Switch Insulator
8.
A-11388-2
Plate
&
Reset Assy.
21.
4002-01105-08
Mach. Screw, 2-56 x
1/2
9.
4700-00072-00
Flatwasher,
17/64
x
1/2"
22.
01-8240
Nut Plate
10.
10-392
Spring
23.
A-14908
Target Knock Down Assembly
11.
20-8712-25
"E"-Ring
a) 01-8647-L
Actuator
12.
01-10183
Switch Bracket
b) A-14913
Frame
&
Eyelet Assembly
13.
4006-01003-03
Mach. Screw, 6-32 x
3/16"
c) SM1-26-600
Coil Assembly
INDIANA JONES 2-27
