A-1S20S-L-2
&
A-1S20S-R-2 Fliptronic II Flipper Assembly
Left Flipper Assembly
" I
~
• Flipper Notes:
1. Each Flipper Assembly is mounted beneath the playfield, in conjuction with the Plastic Flipper
&
Shaft, and Flipper Rubber on the
upper side of the playfield.
2. With the flipper, in the non-activated position, the E.O.S. Switch contacts must have a gap of .062 (±.015) inch. When flipper is
activated switch must close.
3. Any adjustment of the E.O.S. Switch must be made at a minimum distance of 0.25 inch from the switch body.
4. Longer blade of E.O.S. Switch must be straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite™ 245 when reataching screws to the Flipper Stop Assembly, the Solenoid Bracket, and the Flipper Bushing.
INDIANA JONES 2-17
