IMPORTANT NOTICE
PLEASE READ
Pinball games are now equipped with a SAFETY FEATURE to
prevent shocks from the solenoid circuit when the coin door is
opened.
A new interlock switch assembly (part no. A-17077),
located at the left of the coin door opening, has been added to the
game. This assembly is a bracket containing the existing memory
protect switch on the bottom and a new interlock switch on the top.
When the coin door is opened, this new interlock switch opens,
breaking the connection to the +SOV and +20V winding of the
transformer secondary.
A special tool called the Service Switch Actuator is provided for the
serviceman/technician that repairs the game. This tool is painted
yellow and located in a bag stapled inside the cabinet.
The
Service Switch Actuator slips over the interlock switch and holds it
closed while the coin door is opened, allowing the serviceman to
test and repair the solenoid circuit.
Hold the top interlock switch in, then slide the short end of the
Service Switch Actuator over the top of the interlock switch bracket
and the long end over the center of the switch plunger to hold it in.
NEW INTERLOCK SWITCH
