A-14039
Dot Matrix Controller Board
N
:!
J603 ~
J601
10
2
20
30
J602
In :0
~20
J606
TI
8
,
~
5
1
J604
J601, 34-pln Ribbon Cable data, To/from J202; J903; Pl
J605-1 White, 80VAC, from xformer secondary
J605-2 White, 80VAC, from xformer secondary
J605-3 Violet, 100VAC, from xformer secondary
J605-4 N/C
J605-5 Violet 100VAC, from xformer secondary,
J602, 26-pln Ribbon Cable data, To/from J201
J603, 14·pln Ribbon Cable data, To/from Dot Matrix Display/Driver
J604·1 Orange, -125V, to Display/Driver pin 1
J604-2 Blue, -113V, to Display/Driver pin 2
J604·3 N/C
J604-4 Black, ground, to Display/Driver pin 4
J604-5 Black, ground, to Display/Driver pin 5
J604·6 Gray, +5V, to Display/Driver pin 6
J604-7 Gray-Yellow, +12V, to Display/Driver pin 7
J604-8 Brown, +62V, to Display/Driver pin 8
J606-1 Black, ground, loop from J606-3
J606-2 N/C
J606-3 Black, ground, from Power Driver Brd J117-3
J606-4 Gray, +5V, loop from J606-5
J606-S Gray, +5V, from Power Driver Brd J117-4
J606-6 Gray-Yellow, +12V, loop from J606-7
J606-7 Gray-Yellow, +12V, from Power Driver Brd Jl17-2
INDIANA JONES 3-30
