A-12742-50017
CPu
Board
o
- N
00
o.
00
o
D
g 8
• D
c....
gg
N
00 ~
gg ~
0.00
g g
.0
J205
J207
J209
FOJlOOOClooooollo.ooooooollooo*oooool
12
19 19 1"---
J201, 26-pln Ribbon Cable,
data, Tolfrom J602
J202, 34-pln Ribbon Cable,
data,
To/from
J903; P 1; J601
J203-Not Used
J204, 26-pln Ribbon Cable, data Tolfrom 8-Driver Board J1
J20S - 1
J20S - 2
J20S·3
J20S - 4
J20S -
5
J20S - 6
J20S -7
J20S - 8
J20S - 9
J20S - 10
J20S - 11
J20S - 12
Orange-Brown, ded. sw. row 1, to Coin Door Brd J1-14
Orange-Red, ded. sw. row 2, to Coin Door Brd J1-13
Orange-Black, ded. sw. row 3, to Coin Door Brd J1-12
Orange-Yellow,
ded. sw. row 4, to Coin Door J1-17
N/C
Orange-Green, ded. sw. row 5, to Coin Door Brd J1-11
Orange-Blue, ded. sw. row 6, to Coin Door Brd J1-10
Orange-Violet, ded. sw. row 7, to Coin Door Brd J1-9
Orange-Gray, ded. sw. row 8, to Coin Door Brd J1-8
Black, ground, to Coin Door Brd J1-15
N/C
Orange-White, sw. enable, to Coin Door Brd J1-18
J206-1 N/C
J206-2
N/C
J206-3
N/C
J206-4
N/C
J206-S N/C
J206-6
N/C
J206-7
N/C
J206-8
N/C
J206-9 N/C
J207-1 Green-Brown, sw. col. 1, to playfield switches
J207-2 Green-Red, sw. col. 2, to playfield/cabinet
switches
J207-3 Green-Orange, sw. col. 3, to playfield switches
J207-4 Green-Yellow, sw. col. 4, to playfield switches
J207-S Green-Black, sw. col. 5, to playfield switches
J207-6 Green-Blue, sw. col. 6, to playfield switches
J207-7 Green-Violet, sw. col. 7, to play field switches
J207-8 N/C
J207-9 Green-Gray, sw. col. 8, to playfield switches
J208-1 N/C
J208-2 N/C
J208-3 N/C
J208-4 N/C
J208-S N/C
J208-6 N/C
J208-7 N/C
J208-8 N/C
J208-9 N/C
J209-1 White-Brown, sw. row 1, to playfield switches
J209-2 White-Red, sw. row 2, to playfield switches
J209-3 White-Orange, sw. row 3, to playfield switches
J209-4 White-Yellow, sw. row 4, to playfield switches
J209-S White-Green, sw. row 5, to playfield switches
J209-6 N/C
J209-7 White-Blue, sw. row 6, to playfield switches
J209-8 White-Violet, sw. row 7, to playfield switches
J209-9 White-Gray, sw. row
8,
to playfield switches
J210-1 Black, ground, from Power Driver Brd J114-5,7
J210-2 N/C
J210-3 Black, ground, from Power Driver Brd J114-5,7
J210-4 Gray, +5V, from Power Driver Brd J114-3,4
J210-S Gray, +5V, from Power Driver Brd J114-3,4
J210-6 Gray-Green, +12V, from Power Driver Brd J114-1,2
J210-7 Gray-Green, +12V, from Power Driver Brd J114-1 ,2
J211, 34-pln Ribbon Cable,
data, To/from J113
J212-1 Green-Brown, sw. col. 1, to Coin Door Brd J1-1
J212.2 Green-Red, sw. col. 2, to Coin Door J1-7
J212-3 Green-Orange, sw. col. 3, to Gun Handle assembly
J212-4 White-Brown, sw. row 1, to Coin Door Brd J1-6
J212-S N/C
J212-6 White-Red, sw. row 2, to Coin Door Brd J1-5
J212-7 White-Orange, sw. row 3, Coin Door Brd J1-4
J212-8 White-Yellow, sw. row 4, to Coin Door Brd J1-3
INDIANA JONES 3-28
