A-16384-1
Flipper Opto PCB Assembly
~
0
-u
--i
oL
0
~
~
0
-u
--i
oL
0
'"
88
~
.--
/
0
SWl
0
SW2
0
GND
0
GND
•
KEY
0
+12VDC
0
+12VDC
-
I--
L__
I-
...•
=
r------"-'....__..._-._j
2
Left Side Flipper Cabinet Opto Switch Board
J1-1 Blue-Gray from Fliptronic II Board J90S-2
J1-2
N/C
J1·3
N/C
J1·4 Orange from Fliptronic II Board J90S-6
J1·5
N/C
J1-6 Gray-Yellow from Fliptronic II Board J904-2
J1·7 Gray-Yellow from Fliptronic II Board J904-2
Right Side Flipper Cabinet Opto Switch Board
J1·1 Blue-Violet from Fliptronic II Board J90S-1
J1·2
N/C
J1·3 Orange from Fliptronic II Board J90S-6
J1·4 Orange from Left Flipper Opto Assembly J1-4
J1·5
N/C
J1·6 Gray-Yellow from Left Flipper Opto Assembly J1-6
J1·7
N/C
INDIANA JONES 3-14
