High power Solenoid Circuit
Drive
Power
+50V
J130
I
Pisyfieid
I
or
I
Bsckbox Coli
I
Violet-xxx
2.7Kn
I
I
Violet-Yellow
lOOlLf
SOV
- - -
- -
-
-
-
-
-
- - -
-
-
-
-
-
- -
- - - -
-
-
- - -
- -
-
- -
-
-
~
The microprocessor toggles the output of the 74LS374. When point "A" drops low, point "S" the collector of the 2N5401
transistor is high. A high at point "S" causes point "C" the collector of the TIP102 transistor, and point "0" the emitter of
the TIP36 transistor to drop low. When point "0" is low the coil is grounded through the transistor and the coil turns On.
The coil shuts Off when point "A" toggles high.
Low power Solenoid Circuit
: POWER DRIVER BOARD
Drive
Power
Pisyfieid
or
Bsckbox Coli
Brown-xxx
, Violet-Orange
The microprocessor toggles the output of the 74LS374. When point "A" is low, point "S" the collector of the 2N5401
transistor is driven high. A high at point "S" turns On the TIP102 transistor and causes point "C
N
to drop low. When
point "C" is low the coil is grounded through the transistor and the coil turns On. The coil shuts Off when point "AN
toggles high.
INDIANA JONES 3-8
