SWITCH LOCATIONS
Item Switch No.
Where Used
F1 SW-1A-194
Lwr Rt. Flipper EOS
F2 A-16384-1
Lwr Rt. Flipper Cab.
F3 SW-1A-194
Lwr Lt. Flipper EOS
F4 A-16384-1
Lwr Lt. Flipper Cab.
F5 A-13609
Center Drop Bank Left
F6 A-13609
Center Drop Bank Mid.
F7 A-13609
Center Drop Bank Right
F8 5647-12693-21
Left Ramp Made
11 5647-12693-31
Single Drop Target
12 20-9663-12
Buy-in Button
13 20-9663-11
Start Button
14 A-6502-A
Plumb Bob Tilt
15 A 12688
Left Outlane
16 A-12688
Left Return Lane
17 A-12688
Right Return Lane
18 A-12688-1
Right Outlane Top
21
SW-1A-117
Slam Tilt
22
5643-09288-00
Coin Door Closed
23
Not Used
24
5643-09288-00
tAlways Closed
25
A 12688
(I)ndy Lane
26
A 12688
I(n)dy Lane
e(
27
A-12688
In(d)y Lane
28
A-12688
Ind(y) Lane
31
5647-12133-11
Left Eject
32
5647-12693-25
Exit Idol
33
SW-1A-114 (kick)
Left Slingshot
G/,
SW-1 A-120 (score")
34
5647-12133-12
Gun Trigger
35
SW-11A-37
Left Jet Bumper
,
,
35
SW-11A-37
Right Jet Bumper
G'
37
SW-11A-37
Bottom Jet Bumper
38
A-16816-4
Center Standup Target
41
A-16908 (LED)
Left Ramp Enter
A-16909 (trans.)
42
A-14231 (LED)
Right Ramp Enter
A 14232 (trans.)
43
A-14231 (LED)
Top Idol Enter
A-14232 (trans.)
44
A-14231 (LED)
Right Popper
A-14232 (trans.)
45
A-14231 (LED)
Center Enter
A·14232 (trans.)
46
5647-12693-56
TopPost
47
A 14231 (LED)
Subway Lockup
A 14232 (trans.)
48
SW-1A-114 (kick)
Right Slingshot
SW-1A-120 (score")
51
A-14691-4
Advent(u)re Target
52
A-14691-4
Adventu(r)e Target
53
A-14691-4
Adventur(e) Target
54
A-12688
Left Loop Top
55
A 12688
Left Loop Bottom
56
A-12688
Right Loop Top
57
A-12688
Right Loop Bottom
58
A-12688
Right Outlane Bottom
61
A 14691-4
(A)dventure Target
62
A 14691 4
A(d)venture Target
63
A 14691-4
Ad(v) enture Target
64
A 16418
Captive Ball Back
65
A 12688
Mini Top Left
66
A-12688
Mini Mid. Top Left
67
A 12688
Mini Mid. Bottom Left
68
A 12688
Mini Bottom Left
71
A 14231 (LED)
Captive Ball Front
A 14232 (trans.)
72
A 16908 (LED)
Mini Top Hole
A-16909 (trans)
73
A-16908 (LED)
Mini Bottom Hole
A-16909 (trans.)
74
5647-12693-21
Right Ramp Made
75
A-12688-1
Mini Top Right
76
A-12688-1
Mini Mid. Top Right
77
A-12688-1
Mini Mid. Bot. Right
78
A-12688-1
Mini Bottom Right
81
A-16927 (LED)
Trough 6
A-16926 (trans.)
82
A-16927 (LED)
Trough 5
A-16926 (trans.)
83
A-16927 (LED)
Trough 4
A-16926 (trans.)
84
A-16927 (LED)
Trough 3
A 16926 (trans)
G)
CD
Item Switch No.
Where Used
85
A-16927 (LED)
Trough 2
A-16926 (trans.)
86
A-16927 (LED)
Trough 1
A-16926 (trans.)
87
A-16927 (LED)
Trough Top
A-16926 (trans.)
88
A-12688
Shooter
91
A-14231 (LED)
Wheel Position 1
A-14232 (trans.)
92
A-14231 (LED)
Wheel Position 2
A-14232 (trans.)
93
A-14231 (LED)
Wheel Position 3
A-14232 (trans.)
94
A-16657
Mini Plfd Right Umit
95
A-16657
Mini Plfd Left Umit
t
Not Shown
" The Score slingshot switches have diodes across them.
