A·14787
Juggler Assembly
Item Part Number
1.
11-1036
2.
A-14722
3.
A-14729
4.
31-1637
5.
03-8365-10
6.
02-4426-1
7.
23-6645
8.
01-10284
9.
01-10268
10. A-14935
11. A-12336-1
12. 4406-01119-00
13. 4106-01033-08
14. 4106-01115-06Y
15.
*
16. H-14892
17. 03-7655-4
Description
Mini Playfield
Ball Guide Assembly
Ball Guide Assembly
Plastic Overlay
Post
Post
Bumper Pad
Jungle Mounting Bracket
Deflector Bracket
Lug, Diode & Lamp Assy.
Socket & Bulb Assembly
Hex. Nut, #6-32 ESN
Sh. Metal Screw, #6 x 1/2
Sh. Meal Screw, #6-20 x 3/8
Playfield Plastic
Juggler Harness
Harness Clip
Cable List
Part Number
H-11835
H-13870
H-14020
H-14582
H-14583
H-14584
H-14790
H-14792-1
H-14792·2
H-14884
H-14885
H-14886
H-14887
H-14888
H·14889
H-14890
H·14891
H·14892
H-14893
H·14894
H-14895
H-15011
Note:
*
=
Not available for individual sale.
Description
Knocker Cable
Black Jumper Cable
Cable
Secondary Cable
Logic Power Cable
Dot Matrix Display Cable
A.C. Cable
A.C. Jumper Cable
A.C. Jumper Cable
Playfield Switch Cable
Playfield Lamp Cable
Playfield Solenoid Cable
Cabinet Cable
Insert Cable
Flash Cable
Ramp Sw~ch Cable
3-Lamp Stop Cable
4-Lamp Juggler Cable
Opto Transmitter Cable
Opto Detector Cable
Crown Cable
Speaker Panel Cable
Hurricane 2-28
