A-13595-3 3-Bank Drop Target Assembly
@
0
o
00000
Item Part Number
Description
1.
A-13593-3
2.
A-11397
3.
4408-01119-00
4.
AE-26-1200
5.
03-7066-4
6.
A-11389
7.
01-8413
8.
4010-01025-14
9.
03-8036
10.
4700-00072-00
11.
10-392
12.
20-8712-18
13.
23-6626
14.
C-13205
15.
20-8712-25
16.
10-364
17.
4700-00016-00
18.
03-8334-3
19.
4004-01005-04
3-Bank Drop Tgt. Sub-Assembly
Stop Bracket Assembly
Nut, 8-32 ESNA
Coil Assembly
Coil Tubing
Plunger Reset Plate
Coil Mounting Bracket
Mach. Screw, 10-32 x 7/8
Target, Plain
Flatwasher, 17/64 x 1/2 x 21ga.
Spring
"E"-Ring, 3/16" Shaft
Rubber Grommet
3-Bank Opto Board (See p. 2-13)
"E"-Ring, 1/4" Shaft
Extension Spring
Flatwasher,
3/16
x 7/16 x 17ga.
Target, 3-15/16"
Mach. Screw,
4-40
x
1/4"
Hurricane 2-21
