A-15318-R
A-15318-L
Flipper Assembly (Right)
Flipper Assembly (Left)
Item Part Number
Description
Flipper Assembly Notes ...
1.
B-13104-R
Flipper Base Assy, Right
1. Each Flipper Assembly on the Lower Playfield is
t
B-13104-L
Flipper Base Assy, Left
mounted beneath the playfield, in conjunction with
2.
B-13882-R
Crank Link Assembly, Right
the plastic Flipper Paddle and Shaft (20-9250)
and Flipper Rubber (23-6519) on the upper side
t
B-13882-L
Crank Link Assembly, Left
of the playfield.
3.
A-12111
Flipper Stop Assembly
2. The tip of the EOS Switch must travel
4.
FL-11630
Flipper Coil (Red)
0.150
(+
.010, - .000) inch, before the contacts fully
a)
*
Coil Tubing
open, with the f~pper in the actuated position.
5,
01-7695
Solenoid Bracket
The EOS Switch contacts must have a gap of
6,
03-7568
Flipper Bushing
0.062
(±
.015) inch. Adjustment of the EOS Switch
must be made at a minimum distance of 0.25 inch
7.
10-364
Spring
from the switch body.
8.
03-7811
End of Stroke (EOS) Sw.
3.
All moving elements of the assembly must operate
9.
5045-12098-00
Capacitor, 2.2IlFd, 250v, 20%
freely, with no evidence of binding.
10.
20-6516
Speednut, Tinnerman
4.
For coil replacement, remove the Solenoid Bracket
11.
'"
Ty-Wrap, Nylon
(Item 5) to prevent screw damage.
12.
23-6577
Bumper Plug
5. Use Loctite™ 242 when reattaching screws to the
13.
4105-01019-10
Sh. Metal Screw,#5 x
5/8
Flipper Stop Assembly, the Solenoid Bracket, and
the Flipper Bushing.
14.
4701-00002-00
Lockwasher, #6 Split
6. When replacing their Bumper Plug (item 12) to
15.
4010-01066-06
Cap Screw, 10-32 x
3/8,
SH
restore proper flipper operation, readjust the flipper
16.
4701-00004-00
Lockwasher, #10 Split
paddle and shaft position.
17.
4006-01005-06
Mach. Screw, 6-32 x
3/8
P-RH-S
7.
Solid-color blue wire connects to the banded end
18.
4406-01117-00
Nut, 6-32 Hex.
of each diode, mounted on the connector end of the
Flipper Coil (item
4).
Trace-color wire connects to
19.
4006-01017-04
Mach. Screw, 6-32 x
1/4
P-RH-S
the unbanded end of the diode.
20.
*
Wire, 18 AWG, Blue
21.
*
#18 Vinyl Sleeve
22.
4008-01079-05
Cap Screw, 8-32 x 5/16
23.
*
Tape, Double-sided
24.
01-9375
Switch Mounting Bracket
25.
4701-00003-00
Lockwasher, #8 Split
Notes:
1. '" '" Not available for individual
sale.
2.
t
=
ltsms for Left Flipper Assembly Only.
Hurricane 2-14
