Press the Enter button to activate the Test Menu. once the menu name is shown under the Main
Menu. Then. use the Up or Down button to cycle through the Test Menu selections. Press the
Enter button to activate the desired test when that test appears in the displays.
T.
Test Menu
T.l Switch Edges
T.2 Switch Levels
T.S Single Switch
T.4 Solenoid Test
T.5 Flasher Test
T.6 General
Illuminatlen
T.7 SOWld
&
Music Test
T.8 Single Lamps
T.9 All Lamps
T.lO Lamp& Flasher Tests
T.11 DisplayTest
Note:
During the Switch Tests - unless otherwise stated - a flashing cross indicates your
location in the matrix, a square indicates a closed switch. and a dot indicates an open switch.
For all switches. the number on the left indicates the column. the number on the right
indicates the row. Example- Switch 23 means 2nd column. 3rd row.
T.I Switch Edges
To activate the Switch Edges Test, from the Test Menu. press the Enter button.
Press each
switch one at a time. The name and number of the switch is shown in the display. If a switch
other then the one pressed. or no switch at all is indicated. the system has detected a problem
with the switch circuit.
To test the Left and Right Flipper switches. press the Left or Right Flipper button. The flipper
name and switch number should show in the display. Any other results indicate the system
has detected a problem with the flipper switch circuit.
Press Escape to return to the Test Menu. Press the Up button to display the next test, (or the
Down button to return to a previous test). Press the Enter button to activate that test.
T.2 Switch Levels
Once the test name is shown under the Test Menu. press the Enter button. This test
automatically cycles through all switches that are detected closed. The name and number of
each switch that is detected is shown in the display.
A filled square indicates the switch
position in the matrix.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test.
(or the Down button to return to a previous test). Press the Enter button to activate that test.
T.S Single Switches
Once the test name is shown under the Test Menu. press the Enter button. The Single Switch
Test isolates a particular switch by blocking signals from all other switches. Use the Up or
Down buttons to select the switch to be tested. Press the Start button to obtain wire color.
connector, and fuse information of any switch when that switch is displayed.
Hurricane 1-13
