Ramps
2-28
Ramps
•
A-13894 Lower Ramp Assy
A-13895 Upper Ramp Assy
Item Part No.
Description
Hem Part No.
Description
1 A·12887
Socket & Bulb Assembly
1 A-14197
Impact Bracket Assembly
a)
24·8768
Bulb #555 (6.3v, .25A.)
2 A-14231
LED Assembly
b)
24-8807-1
Socket-Wedge Base
3 A-14232
Photo Transistor Assembly
2 A-14170
Lft. Sign Bracket Assembly
4 A-14285
Plate & Plastic Assy.
a)
A-8882
Light Socket Assy. wlDiode
5
A-14306
Upper Ramp Sub-Assy.
b)
01-9914
Bracket
6 H-14252-14
Opto Cable
c)
03-8063-4
Light Bulb Sleeve, Red
7 H-14252-7
Upper Ramp Cable
d)
31-1-50003-38 Playfield Plastic, Screened
8 01-8240
Nut Plate, #2-56
3 A-14266
Mini Dome & Plastic Assy.
9 01-9476-2
Ramp Switch - Bracket
4 A-14307
Lower Ramp Sub-Assy.
10 01-9912
Ramp Flap
5 H-14252-13
G.!. Lamp Cable
11 01-9951
Deflector Bracket
6 H-14252-8
Lowsr Ramp Cable
12 02-4252-12
F-F 6-32x3/4
7 01-8795
Flap
13 03-8063-2
Light Bulb Sleeve-Green
8 01-9476-2
Ramp Bracket Switch
14 03-8063-4
Light Bulb Sleeve-Red
9 01-9499
Bearing Plate
15 03-8063-6
Light Bulb Sleeve-Yellow
10 02-4252-12
F-F, 6-32 x
3/4
16 03-8458
Ramp
11 03-8369
Switch Cover
17 03-8506
Base Opto Mt-Black
12 03-8457
Lower Ramp
18 03-8506-1
Base Opto Mt-White
13 4002-01005-08 Mach. Screw, 2-56 x 112
19 20-9646
Switch Cover Protector
14 4006-01017 -06 Mach. Screw, 6-32 x
3/8
20 24-8768
Bulb #555 (6.3v, .25A.)
15 4006-01027-06 Mach. Screw, 6-32 x
3/8
21 24-8821
Socket
16 4406-01128-00 Nut, 6-32 KEPS
22 4002-01005-08 Mach. Screw, 2-56 x 112
•
17 4701-00024-00 Lockwasher, #2 Split
23 4104-01001-06 Sh. Metal Screw, #4 x
3/8
18 5070-06258-00 Diode, 1N4001, 1.0A.
24 4106-01004-06 Sh. Metal Screw, #6 x
3/8
19 5647-12073-21 Microswitch
25 4701-00024-00 Lockwasher, #2 Split
26 5070-06258-00 Diode, 1N4oo1, 1.0A.
27 5647-12073-21 Microswitch
A-13896
A-13896
.,
X-Over Wire Chute Assembly
Right Wire Chute Assembly
Item Part No.
Description
Hem Part No.
Description
1 H-14252-2
Ramp Switch Cable
1 H-14252-11
Wireform Switch Cable
2 01-8240
Nut Plate, #2-56
2 01-8240
Nut Plate, #2-56
3 01-8600
Insulator
3 01-8600
Insulator
4 02-4436-15
F-F Spacer,
1-7116
4 02-4436-15
F-F Spacer,
1-7/16
5 12-6935
Wire Chute
5 12-6936
Wire Chute, Right
6 4002-01105-07 Mach. Screw, 2-56 x
7/16
6 4002-01105-07 Mach. Screw, 2-56 x
7/16
7 4408-01119-00 Nut, 8-32 ESN
7 4408-01119-00 Nut, 8-32 ESN
8 5070-06258-00 Diode 1N4001, 1.0A.
8 5070-06258-00
0
Diode, 1N4001, 1.0A.
9 5647-12073-21 Microswitch
9 5647-12073-21 Microswitch
•
