W14 W15 W16 W17 W18
American*
In
In
In
In
In
French
In
In
In
Out
In
German
In
In
In
In
Out
'"All of the above jumpers in, or two or more of these cut
•
FUNHOUSE Jumper Chart
FUNHOUSE Solenoid Table
•
Sol.
Wire
Oennecttons
Solenoid Part Number
Solenoid
Driver
Flashlamp Type
No.
Function
Type
Color
Trnstr
01 Outhole
High Power Vio-Brn Jl30-1
Q82
AE-26-1200
02 Ramp Diverter
High Power Vio·Red Jl30-2
Q80
AE-26-1200
03 Kickbig
High Power Vio·Orn Jl304
Q78
AE-26-1500
04 Tunnel Kickbig
High Power Vio·Yel
J130-5
Q76
AE.26-1200
05 Trap Door Open
High Power Vio·Grn J130-6
Q64
AE·26·1500
06 Trap Closed
High Power Vio·Blu Jl30-7
Q66
SMl·26-600
07 Knocker
High Power Vio·Blk JI30-8
Q68
AE·23·800
08 Multi-ball Release
High Power Vio-Gry JI30·9
Q70
A·14189
09 Upper Left Jet Bumper
Low Power
Brn-Blk J127-1
Q58
AE-26-1200
10 Upper Right Jet Bumper
Low Power
Brn-Red J127-3
Q56
AE-26-1200
U Lower Jet Bumper
Low Power
Brn-Orr
J127-4
Q54
AE-23-1200
12 Left (sling) Kicker
Low Power
Brn-Yal
J127-5
Q52
AE-26·1500
13 Right (sling) Kicker
Low Power
Brn-Grr
J127-6
Q50
AE-26-1500
14 Steps Gate
Low Power
Brn-Blu J127.7
Q48
SZ-34-3500
15 Trough
Low Power
Brn-Vio Jl27-8
Q46
AE-26-1200
16 Dummy Eject Hole
Low Power
Brn-Ory J127·9
Q44
AE·26-1500
17 3 Blue Flashers
Flasher
Blk·Brn JI26-1
Q42
#906
18 Dummy Flasher
Flasher
Blk·Red JI26-2
Q40
#906
19 2 Clock Flashers
Flasher
Blk·Orn Jl26-3
Q38
#906
20 2 Superdogs
Flasher
BIk·Yel
Jl26·5
Q36
#906
21 Mouth Motor
Special
BIu·Grn J126-6
Q28
A·13997
22 Up/Down Driver
Special
Blu·Blk JI26·7
Q30
C-13963
23 3 Red Flashers
Special
Blu-Vio Jl26-8
Q34
#906
24 3 Clear Flashers
Special
Blu-Gry J126·9
Q32
#906
25 Eyes Right
Special
Blu-Brn J122·1
Q26
SM-30-1100
26 Eyelids Open
Special
BIu-Red J122·3
Q24
SM-30-1l00
27 Eyelids Closed
Special
Blu·Orn JI224
Q22
SM-30-1100
28 Eyes Left
Special
BIu·Yel
J122·5
Q20
SM-30-1100
GenerallllumlnatJon Circuits
G.I.
Wht-Brn
01 Upper Backglass
JI20-7
Ql8
#555
02 Front Playfield
G.I.
Wht.Vio JU9-l
QI0
#555
03 Rear Playfield
G.I.
Wht-Yel
Jl21-9
Q14
#555
04 Center Backgless/Rt Rear Pfd G.I.
Wht.Orn J120-8
Q16
#555
05 Top Playfiold
G.1.
Wht-Grn Jl20·10
Q12
#555
Lower Right Flipper
BIu-Yel
JI09·7
FL-U630
Lower Left Flipper
Gry-Yel
JI09-5
FL-11630
Upper Left Flipper
Gry-Yel
JI09-5
FI-1l753
•
