#906 - "FOUR MILLION BoCol!
INSTALLATION AND GENERAL GAME OPERATION INSTRUCTIONS
INSTALLATION
On all games there are certain items that should be checked after
shipment
0
These are visual inspections which may avoid time con-
suming service work latero Minor troubles caused by abusive hand-
ling in shipment are unavoidableo Cable plugs and sockets may be
loosened, switches (especially tilt switches) may go out of adj-
ustment
o
Plumb bob tilt switch should always be adjusted after
game is set on location and leg levelers are adjusted.
Visual inspections before plugging in line cord: -
1. Check that all cable plugs are firmly seated in proper sockets.
2. Check that cables are clear of all moving parts and relayso
3. Check for any wires that may have become disconnected.
40 Check switches for loose solder or other foreign material that
may have come loose in shipment and could cause shorting of
contacts.
5. Check wires on relay coils for proper soldering, especially
the bare (common) wire connecting a row of relay coils
o
Cold
solder connections may not show up in factory inspection
4
but
vibration in shipment may break contact.
6. Check that fuses are firmly seated and making good contact.
70
Check (manually) the stepping and resetting of all step-up
units
o
The wiper action should not be sluggish.
8. Check transformer for any foreign material shorting across
wiring lugso
90 Check wiring of transformer to correspond to location voltageo
(Transformer wiring card in front cabinet.)
Before line cord in plugged in: -
Check all plugs and sockets and dress cables:
(A) Plugs in correct sockets.
(B) Plug~ securely seated in sockets.
(C) Dress cables away from relayso
Check adjustment of the three (normally open) tilt switches:
(A) Panel tilt on bottom of playfield panel.
(B) Plumb-bob tilt on left side of cabinet near front door.
(C) Ball tilt above plumb-bob tilt.
Insert one of the four balls into ball tilt assembly and
adjust bracket so ball will rollover switch blade if
front of cabinet is raised
o
