FISH TALES 2-40
Playfield Parts
l1.tm.
f1u1
Number
Description
N.21
Shown
1
A-8039-3
Outhole
A-13204-5000S
Bottom Arch Assembly
2
C-9638
Ball Release
12-6842
Wire Fence
a}
B-9362-R-3
Coil
&
Bracket Assembly
16-50005-1
Instruction Card
3
A-14525
Shooter Lane Kicker
20-9041
Tinnerman Speednut
4
20·9691
Level
20·9045
Instruction Card Cover
a)
03-8633
Level Mount
23-6313·1
Rubber Grommet
b)
01·10621
Strike Plate
31·1 008-50005
Screened Bottom Arch
5
A·15205 -R-2 Ri9ht Flipper Assembly
A-15058
Flipper Cabinet Switch
a)
20-9250-6
Yellow Flipper Paddle & Shaft
01-3569·1
Ball Return Runway
6
A-15403-2
Right Flipper Paddle Return
03-8674-2
Jet Bumper Mylar
•
7
B-12665
Kicker Assembly
03-8674-3
Small Playfield Mylar
a)
A-14369-R
Coil
&
Bracket
03-8674-4
Boat Mylar
8
A-15412
Right Wire Ramp
20-6500
Steel Ball
•
9
A-15741
Standup Target
10
01·10489
Shooter Ramp Brackel
11
A-15658-2
Oblong Target
12
A-15211
Drop Target
13
A-15405
Reel Enter Ramp
14
A-15109
Boat Assembly
a)
A-14691-5
Captive Ball Target
15
D-11335-1
Ball Popper
16
A-15055
Boat Ramp
17
A-15373
Ball Guide Un~
18
12-7033
Wire Ball Guide
19
B-9361-R-l1
Ball Eject
a}
B-9362-R-3
Coil
&
Bracket
20
12-7024-2
Wire Ball Guide
21
12-7024-1
Wire Ball Guide
22
B-l0732-L
Ball Gate Assembly
a)
A-14422
Ball Gate Actuator
23
12-7011
Wire Ramp Guide
24
A-15401
Spin Target
&
Ught Assembly
25
A-14945
Fish Reel Unit
a}
14-7967
Motor
b)
A-15340
EMI Motor Board
c)
A-14231
LED Board
d)
A-14232
Trans Board
e)
A-13901-1
Oplo Switch Board
26
A-14947
Catapult
27
A-15413
left Wire Ramp
28
12-6466-10
Wire Guide
29
B-12665
Kicker Assembly
..
a)
A-15749
Coil
&
Bracket Assembly
30
A-1S403-1
Left Flipper Return
31
A-15205-L-2
Left Flipper Assembly
a)
20-9250-6
Yellow Flipper Paddle
&
Shaft
32
A-13204-50005 Bottom Arch Assembly
33
8-9414-3
Jet Bumper Assembly
a)
8-12030-2
Switch Assembly
b)
A-9415-2
Coil
&
Bracket Assembly
