FISH TALES
2-32
Coin Door Assembly
A·14148-1
U.S.A. Door with Decals
09·17002·x
2·Chute Door
09·17003-x
s-chute
Door
("x·
is
the
country designator)
Item
Pari No.
Description
Quantity
,
27-1038
BUllon Cover
2or3
2
27-1041-1"'" 58 Price Panel
2 or3
3
27-1026-1 ....•17 Coin Entry Plate
2 or3
4
27-1016
lock Assembly
1
5
27-1061-,
Coin Return - Bezel
1
6
27-1062
Coin Return Flap
1
7
27-,021
Button Housing - 2-s101
1
27-1022
Button Housing - 3-slot
1
8
27-1111
Intertock Switch
1
9
27-1006-1
Coin Door, 2-Slol
1
27-1007-1
Coin Door, 3-Slol
1
10
27-1005
Coin Door Frame
1
11
27-1003
MlC Screw, 6-32 )(
3116
4
12
5641- 12724-00
Diagnostic SWitch
I
13
27·1101
MlC Screw, 4-40
X
1/4
2
14
01·9885
Bracket, Diagnostic Switch
1
15
03-7601-4
Button,Red
2
03-7601-7
Button, Black
2
16
27·1078
MlC Screw, 6-32
X
318
20r3
17
27·1039
Conical Spring
20r3
18
27-1079
Self-tapping Screw, #6
X
1/4
2
19
27·1077-1
Coinbox Cover
1
20
27-1066
Slam Switch
1
21
27·1067
MlC Screw, 4-40 x
1/2
2
22
27·1017
Nul (key)
1
23
27·1012
locking Cam
1
24
27-1011
Locking Arm
2
25
27-1020
Washer
1
26
27-1018
Star Washer
1
27
27-1019
MlC Screw,
1/4-28
x 5116
1
28
27-1089
R-Ring
1
29
27-1083
Retainer
1
30
27-1081
Coin Inlet Chute
2or3
31
27-1088
Cable Clamp
2or3
32
27-1025
Key Hook
1
33
27-1086
Washer, #6
20r3
34
27-1078
MlC Screw, 6-32 x 318
lor 2
27-1113
MlC Screw, 6-32 x
7/16
1
35
27-1079
Sell-lapping Screw, #6 x
1/4
2or3
36
27-1084
lamp Sockel
2or3
27-1085
Lamp
20r3
~
37
27-1096
Self-tapping Screw, #5 x 3/8
2or3
38
27·1087
MlC Screw, 6-32 x 518
2or3
39
27-1082
Lever Arm
20r3
40
27-1097
Switch Cover
20r3
41
27-1091-1
Coin Accepl Chute
20r3
42
27-1075
Wire Form (Small)
20(3
or
27-1093
Wire Form (Large)
43
27-1094
MlC Screw, 4-40 x
718
40r6
44
27-1087
MlC Screw, 6-32 x
5/8
40r6
45
27-1086
Washer, #6
40r6
46
27-1095
NUl, 4-40 ESNA
40r6
47
27-1076-1
Coin Return Box
1
48
27-1078
MlC Screw, 6-32 x
3/8
2
49
27·1092
Microswitch
2 or 3
